Relpol PCB Power Relay 3V dc Coil 12A Switching Current 1 CO RM50N-3011-85-1003

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 3V dc Coil 12A Switching Current 1 CO RM50N-3011-85-1003

Name: Relpol PCB Power Relay 3V dc Coil 12A Switching Current 1 CO RM50N-3011-85-1003
Brand: Relpol
SKU: 202397
Price: 6.86 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	15.3mm
Length	19.5mm
Model	RM50N-3011-85-1003
Width	15.6mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM50N
Maximum Operating Temperature	85°C
Contact Configuration	1 CO
Minimum Operating Temperature	-55°C
Switching Current	12A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	EAC, RoHS
Coil Voltage	3V dc
Switching DC Voltage	110V dc
Switching AC Voltage	110V ac
Coil Power	360mW

Key Features

Features a 1 CO contact configuration suitable for general purpose applications.
Compact miniature relay from the RM50N series with silver alloy contacts.
Supports switching voltages up to 110V AC/DC with a power rating of 1.5 kVA.
Operates efficiently within a temperature range of -55°C to 85°C.
Coil power consumption is low at 360mW for energy-efficient use.
Designed for high shock and vibration resistance to ensure durability.
Ideal for applications in automotive, machinery, and electronic equipment.

Product Description

Relpol RM50N-3011-85-1003 PCB Power Relay features a 3V dc coil voltage and can switch currents up to 12A, providing reliable performance for a broad range of industrial and electronic applications.

This miniature power relay is designed for PCB mounting, making it suitable for integration within circuits requiring compact and efficient switching solutions.

The relay offers a single 1 CO (Change-over) contact configuration with silver alloy contacts that ensure low contact resistance of 100mΩ and robust switching power up to 1.5kVA. It supports both AC and DC switching voltages up to 110V.

Engineered for demanding environments, it operates within a wide temperature range from -55°C minimum to 85°C maximum, and features excellent resistance to shocks and vibrations, thereby enhancing longevity under industrial use.

The coil power rating is 360mW, contributing to lower energy consumption while maintaining effective actuation. Compact dimensions (19.5mm length, 15.6mm width, and 15.3mm height) allow for integration in space-critical applications.

1 CO contact configuration for versatile circuit control. Silver alloy contacts for reliable electrical conductivity and durability. Low coil power ensures efficient operation with minimal energy use. Wide operating temperature range enables operation in harsh environments.

Small form factor ideal for PCB mounting in compact equipment. Suitable for uses in automotive, industrial machinery, and electronic devices. Certified to EAC and RoHS standards ensuring compliance and safety. This power relay is made in Poland and conforms to recognized standards for electrical components, suitable for industrial automation and control systems.

For engineers and designers seeking a dependable miniature power relay for PCB applications, the Relpol RM50N-3011-85-1003 provides a high-quality solution with proven performance. Explore related Power Relays and components for your automation projects on EnvMart.
