ROHM 24V 1W Zener Diode Single Surface Mount 2-Pin SOD-123FL KDZVTR24B
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 0.9mm |
| Length | 3.62mm |
| Model | KDZVTR24B |
| Mount Type | Surface |
| Series | KDZV |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123FL |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 1W |
| Diode Configuration | Single |
| Test Current It | 1mA |
| Maximum Reverse Leakage Current | 10μA |
| Nominal Zener Voltage Vz | 24V |
| Zener Type | Voltage Regulator |
Key Features
- Nominal Zener voltage rating of 24 volts for voltage regulation.
- Maximum power dissipation capacity of 1 watt providing robust durability.
- Compact surface mount design with SOD-123FL package type for PCB integration.
- Operating temperature range from -55°C to 150°C for wide environmental suitability.
- Low maximum reverse leakage current of 10 microamperes ensuring efficiency.
- Test current of 1 milliampere for standard electrical operation.
- 2-pin configuration suitable for voltage regulation circuits.
- KDZV series maintaining ROHM’s high quality semiconductor standards.
Product Description
ROHM KDZVTR24B is a high-quality 24V Zener Diode designed for voltage regulation applications in electronic circuits. It is a single element diode with a maximum power dissipation of 1 watt, housed in a compact SOD-123FL surface mount package featuring 2 pins for easy PCB mounting.
The device supports a wide operating temperature range from -55°C up to 150°C, making it suitable for demanding environments in industrial, commercial, and consumer electronics. This Zener diode exhibits a low maximum reverse leakage current of 10μA at the test current of 1mA, ensuring reliable and efficient voltage stabilization.
Featuring a length of 3.62mm and a height of 0.9mm, the small form factor allows integration in space-constrained designs.
The KDZVTR24B belongs to ROHM’s KDZV series of Zener Diodes, recognized for their robust performance and dependable manufacturing standards, fulfilling typical requirements for electronic power regulation and protection circuits in various electrical and industrial applications.
Nominal Zener voltage of 24V providing precise voltage regulation. Maximum power dissipation of 1W supports moderate power circuit needs. Surface mount type package SOD-123FL ideal for modern PCB assembly. Wide temperature operating range ensures versatility.
Low reverse leakage current minimises power losses. Compact dimensions permit use in tight spaces. Reliable ROHM semiconductor quality and consistency.
This Zener diode is typically employed in electronic circuits requiring stable voltage regulation such as power supplies, industrial control systems, and other semiconductor device protection schemes.
Explore more ROHM semiconductor components and related electronic parts available on EnvMart for comprehensive industrial and electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal Zener voltage rating of this diode is 24 volts, suitable for voltage regulation applications.
This model has a maximum power dissipation capacity of 1 watt, making it suitable for moderate power circuit needs.
It is housed in a compact SOD-123FL surface mount package, designed for easy PCB integration.
The operating temperature range for this diode is from -55°C to 150°C, allowing for use in various environmental conditions.
The maximum reverse leakage current is 10 microamperes at a test current of 1 milliampere, ensuring efficient operation.
This Zener diode features a 2-pin configuration, making it suitable for voltage regulation circuits.
The height of this diode is 0.9mm and its length is 3.62mm, allowing for integration in space-constrained designs.
It uses a single diode configuration, which is typical for voltage regulation applications.
The test current for this diode is 1 milliampere, which is used for evaluating its performance.
The KDZVTR24B is manufactured in India, adhering to ROHM's quality standards.
This diode belongs to the KDZV series, recognized for its robust performance in voltage regulation applications.
It is typically used in electronic circuits requiring stable voltage regulation, such as power supplies and industrial control systems.
