Cosel DC/DC Converter 15V DC, 2A Output, 36-48V DC Input, 30W Power, PCB Mount, 85°C Max Temp MGS304815-R

Cosel MGS304815-R DC/DC Converter delivers a regulated 15V DC output at 2A while accepting a wide DC input voltage ranging from 36V to 48V. This converter offers a maximum output power of 30W and is designed for PCB mounting with a compact 6-pin DIP package measuring 25.4 mm in length and 9.9 mm in width and depth.

The converter features high efficiency at 92%, achieved through a synchronised rectification circuit, reducing energy loss and improving thermal performance. It includes a built-in remote ON/OFF function facilitating control in embedded systems.

Key safety features comprise a 1.5kV AC isolation voltage between input and output, overcurrent protection circuits that reset automatically, and absence of wear-prone aluminium and tantalum electrolytic capacitors, enhancing overall reliability and lifespan.

The output voltage can be fine-tuned externally within a ±10% adjustment range using a variable resistor, allowing optimization for specific applications. The device operates effectively within a temperature range of -40°C to 85°C, suitable for demanding industrial and commercial environments.

Certifications include CE, EN 60950-1, TUV, UL 60950-1, and cULus approvals, confirming compliance with international safety and quality standards. The unit weighs approximately 40 grams and is manufactured in Japan, reflecting high build quality.

Typical applications of the Cosel MGS series DC/DC converters include industrial automation, telecommunications, instrumentation, and power management in electronic devices requiring isolated, efficient voltage conversion on printed circuit boards.

Industry-standard 1 inch by 1 inch package size ensuring compatibility. High efficiency of 92% enabled by synchronised rectification circuit. Built-in remote ON/OFF functionality for flexible control. Robust I/O isolation voltage of 1,500 V DC for safety.

Overcurrent protection circuits that recover automatically increase reliability. Output voltage adjustable via external variable resistor within ±10% range. No aluminium or tantalum electrolytic capacitors ensure high reliability and extended lifespan.

Compact 6-pin DIP package suitable for PCB mount applications. Wide operating temperature range from -40°C to 85°C for harsh environments. Compliance with CE, EN 60950-1, TUV, UL 60950-1, and cULus safety standards. Explore more products in the DC/DC Converter category at EnvMart for diverse power supply solutions offering reliability and precision.
