Cosel DC/DC Converter Dual Output 24 V dc, -24 V dc, 450 mA, 5 V dc and 36 V Input, 10.8 W PCB Mount SUTW100512

Cosel SUTW100512 is a dual output insulated DC/DC converter designed for electronic and power supply applications. It delivers 24 V dc and -24 V dc output voltages at an output current of 450 mA, making it ideal for precise and reliable power conversion. The converter accepts input voltages ranging from 5 V dc to 36 V dc, supporting various industrial voltage sources.

With a maximum output power of 10.8 W and an efficiency rating of 86%, the SUTW100512 ensures energy-efficient operation. Its compact DIP package measuring 45.2 mm in length, 29.3 mm in width, and 29.3 mm in depth is suitable for PCB mount installation, saving space in electronic assemblies.

The device supports remote ON/OFF capability and allows adjustable external output voltage, enabling flexible power management and fine-tuning for various applications. Built-in overcurrent protection circuits enhance safety by preventing damage due to overloads.

Rated for isolation voltage of 500 V ac, this converter provides electrical isolation between input and output, essential for sensitive electronic circuits. The operating temperature range of -40 °C to +85 °C allows use in harsh environmental conditions such as industrial, telecommunications, and instrumentation systems.

This series from Cosel does not include aluminium or tantalum electrolytic capacitors, ensuring longer reliability and stable performance over time. The switching frequency of 1900 kHz allows compact design and reduced electromagnetic interference.

The product is certified for compliance with international safety standards including EN 60950-1, UL 60950-1, cULus, CE, and TUV, assuring high quality and regulatory compliance.

Common industrial applications include power supplies for electronic devices, telecommunications, instrumentation, industrial equipment, and embedded systems requiring stable dual output voltage sources.

Dual isolated outputs with 24 V dc and -24 V dc voltages and 450 mA current rating. Input voltage range from 5 V dc to 36 V dc. High efficiency operation at 86% for reduced power loss. Compact DIP PCB mount package for easy integration.

Wide operating temperature range for industrial environments. Remote ON/OFF and adjustable output voltage for flexible control. Built-in overcurrent protection for device safety. Isolation voltage of 500 V ac for electrical safety.

Compliance with EN 60950-1, UL 60950-1, cULus, CE, and TUV standards. Explore the range of Cosel DC/DC Converters on EnvMart for reliable power management solutions in electronics and industrial systems.
