Cosel Isolated DC/DC Converter 5V DC Output, 2A, 5V DC Input, 4.5V Min Input, 10W, PCB Mount, 7-Pin DIP SUTS100505

Cosel SUTS100505 isolated DC/DC converter is engineered to deliver a reliable 5V DC output at a current of 2A with a maximum power capacity of 10W. It is specifically designed for PCB mounting applications using a 7-pin DIP package which facilitates easy integration into electronic circuits. This converter supports an input voltage range from 4.5V minimum to 5V maximum DC ensuring flexible power source compatibility.

The device features a high isolation voltage of 500V AC which provides superior electrical safety in sensitive electronic environments. With an efficiency rating of 83% and a ripple and noise specification of 200mV peak to peak, this converter ensures stable and clean power delivery. It operates over a wide temperature range from -40°C to 85°C, making it suitable for harsh industrial, laboratory, construction, and manufacturing applications.

The SUTS100505 avoids the use of aluminium or tantalum electrolytic capacitors, thereby enhancing overall reliability and longevity. The product is compact with dimensions measuring 45.2 mm in length, 29.3 mm in width, and 29.3 mm in depth, enabling deployment in space-constrained applications.

Additional features include remote ON/OFF control and built-in overcurrent protection circuits, cooled effectively by convection or forced air. The converter complies with key international standards including CE, cUL, UL 60950-1, EN 60950-1, and TUV, demonstrating its suitability for global industrial and commercial markets.

This product is ideal for use in electronics manufacturing, automation systems, power supply distribution, telecommunications, and other industrial applications requiring stable DC power conversion.

Supports input voltage range from 4.5V to 5V DC. Features 7-pin DIP package type providing easy through-hole mounting. High isolation voltage of 500V AC ensures robust electrical safety. Efficient operation at 83% efficiency with a ripple noise of 200mV Pk-Pk.

Operating temperature range from -40°C to 85°C suitable for industrial environments. Compact dimensions of 45.2mm length, 29.3mm width, and 29.3mm depth facilitate space-saving designs. Includes built-in overcurrent protection and remote ON/OFF capability.

Meets international standards including CE, cUL, UL 60950-1, EN 60950-1, and TUV certifications. Constructed without electrolytic capacitors for enhanced reliability. Explore our catalog for more Cosel DC/DC Converters and reliable power conversion solutions at EnvMart.
