binder Circular Connector, Subminiature, 5 Contacts, Panel Mount Plug Male, IP40, 125V, 3A, Bayonet, Metal 09-0997-00-05
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 125V |
| Brand | binder |
| Orientation | Straight |
| Current | 3A |
| IP Rating | IP40 |
| Mount Type | Panel Mount |
| Housing Material | Metal |
| Contact Material | Brass |
| Series | 710 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shell Size | 10 mm |
| Mating Type | Bayonet |
| Connector Size | Subminiature |
| Plug/Socket | Plug |
Key Features
- The connector features a bayonet mating type ensuring secure and easy connection.
- Designed to carry currents up to 3 amperes at a voltage rating of 125 volts.
- Constructed with a metal housing for durable use in harsh industrial environments.
- Contact material is brass with gold plating, improving conductivity and corrosion resistance.
- Protection rating of IP40 provides protection against solid objects over 1 mm but no water resistance.
- Operates reliably within a temperature range of -40°C to 85°C.
- Connector shell size is 10 mm with straight orientation suitable for panel mounting.
- Connection termination is by solder for strong electrical contacts.
Product Description
binder 09-0997-00-05 circular connector is a subminiature, panel mount plug connector featuring 5 electrical contacts with a bayonet mating mechanism. It supports industrial environments with a robust metal housing that withstands mechanical stresses and temperature variations from -40°C to 85°C. Rated for 3A current and 125V voltage, it provides reliable electrical connectivity in manufacturing, control, and automation systems.
The connector's male contact design facilitates secure and easy installation on panels, complemented by solder termination type for stable contacts. Its IP40 ingress protection rating ensures durability by guarding against intrusion of solid particulates, suitable for indoor dry environments. Gold-plated brass contacts ensure corrosion resistance and quality signal transmission.
This 710 series connector is ideal for industrial electronic components requiring high reliability in compact form factors. The 10 mm shell size and straight orientation allow seamless integration in control panels and instrumentation. Precision bayonet coupling guarantees correct and safe assembly every time.
Common applications include industrial automation, electronic instrumentation, laboratory equipment, and power supplies where reliable connector performance under challenging conditions is essential.
The connector features a bayonet mating type ensuring secure and easy connection. Designed to carry currents up to 3 amperes at a voltage rating of 125 volts. Constructed with a metal housing for durable use in harsh industrial environments.
Contact material is brass with gold plating, improving conductivity and corrosion resistance. Protection rating of IP40 provides protection against solid objects over 1 mm but no water resistance. Operates reliably within a temperature range of -40°C to 85°C.
Connector shell size is 10 mm with straight orientation suitable for panel mounting. Connection termination is by solder for strong electrical contacts. Compact subminiature size allows use in space-constrained electronic setups.
Choose the binder 710 series for dependable industrial circular connectors that combine compact size, robust build, and precise electrical contact configuration. Explore similar high-performance connectors in the Industrial Circular Connectors category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of 125V and a current of 3A.
It has an IP40 ingress protection rating, which protects against solid objects larger than 1 mm but does not provide water resistance.
The connector features a metal housing and brass contacts with gold plating, enhancing conductivity and corrosion resistance.
It operates reliably within a temperature range of -40°C to 85°C.
The binder 09-0997-00-05 has 5 electrical contacts.
This unit utilizes solder termination for strong electrical contacts.
The shell size of this model is 10 mm.
It features a bayonet mating type, ensuring secure and easy connection.
No, the IP40 rating indicates it is suitable for indoor dry environments only, as it does not provide water resistance.
This model has a straight orientation, making it suitable for panel mounting.
The binder 09-0997-00-05 is manufactured in Germany.
It is ideal for industrial automation, electronic instrumentation, laboratory equipment, and power supplies.
