TDK-Lambda DC/DC Converter Through Hole 15 V dc Output 1 A 15 W 9V-36V Input Metal Case CCG15

TDK-Lambda CCG15 DC/DC Converter model CCG15 delivers 15 V dc output at 1 A current and 15 W maximum power through a through-hole mounted metal case. It features a broad input voltage range from 9 V to 36 V dc, supporting reliable operation in ambient temperatures ranging from -40°C to 85°C. This high-efficiency converter (88%) includes shielding on all six sides for effective noise reduction, making it ideal for industrial, laboratory, and commercial applications requiring stable DC power from variable DC sources.

The compact DIP package measures 25.4 mm in length and 9.9 mm in width and depth, with 6 pins for easy PCB integration. Its output voltage can be adjusted between 13.5 V and 16.5 V, and it supports a 500 V dc isolation voltage enhancing safety and signal integrity. Ripple and noise levels are minimized to 95 mV peak-to-peak, ensuring clean power supply critical for sensitive electronics.

Typical use cases include factory automation, process control, communications, broadcast equipment, and test & measurement systems where dependable DC power conversion is essential. The robust metal enclosure also provides shock and vibration resistance.

Wide input voltage range of 9 V to 36 V dc. Output voltage adjustment from 13.5 V to 16.5 V dc. High isolation voltage of 500 V dc between input and output. 6-sided shielding for reduced radiated noise. High efficiency of 88% for power savings.

Compact 25.4mm x 9.9mm x 9.9 mm DIP package. Operating temperature range from -40°C to 85°C. TDK-Lambda is known for reliable power conversion solutions. Explore more DC/DC Converters and power supply products at EnvMart for industrial and commercial electronics needs.
