Schneider Electric TeSys K Reversing Contactor, 230V AC Coil, 3-Pole, 6 A, 3 kW, 3 NO, 690V AC LC2K0610P7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LC2K0610P7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LC2K |
| Power Rating | 3kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 6A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NO |
| Operational Current Ie | 6A |
| Control Circuit Voltage Uc | 230V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Ue Rated Voltage Power circuit | 690 V AC 50/60 Hz, Signalling circuit |
Key Features
- Designed for motor control and resistive load applications.
- Operates with a 230V AC coil and supports 690V AC contact voltage.
- Features 3 poles and 1 normally open auxiliary contact.
- Includes a 3 NO normal state configuration for reliable switching.
- Compact size compatible with DIN rail mounting for easy installation.
- Rated for operation up to 50°C ambient temperature.
- Equipped with screw clamp terminals for secure connections.
- Complies with multiple international standards including IEC, UL, CSA, CCC, EAC, and RoHS.
Product Description
Schneider Electric LC2K0610P7 reversing contactor is a high-quality electrical control device featuring a 230V AC coil, 3 poles, and a 6A current rating. It is designed specifically for motor control and resistive load applications, providing reliable switching capabilities for industrial and commercial environments.
This compact contactor is built to fit DIN-rail mountings with dimensions of 90mm width, 58mm length, and 57mm depth, making it suitable for panel installations where space is limited. The device includes 3 normally open contacts along with an auxiliary contact configured as 1 NO, providing additional signaling or control functionality. Its screw terminal connections ensure secure and easy wiring.
The LC2K0610P7 model complies with recognized international standards such as IEC, UL, CSA, CCC, EAC, and RoHS, highlighting its safety, quality, and environmental certifications. It is certified as a Better World Product designed for disassembly, promoting sustainable product lifecycle management.
Operating temperature ranges from -25°C to 50°C, making it adaptable to various environmental conditions. The contactor is equipped with a mechanical interlock and a pre-wired reversing circuit, enabling simple and effective motor reversing operations without additional wiring complexity.
This reversing contactor is suitable for diverse industrial automation and control applications including motor control centers, HVAC systems, manufacturing processes, and resistive load switching scenarios. It can be complemented with auxiliary contact blocks and thermal relays (such as LA1K, LA2K, LR2K) for enhanced control and protection functionalities.
Designed for motor control and resistive load applications. Operates with a 230V AC coil and supports 690V AC contact voltage. Features 3 poles and 1 normally open auxiliary contact. Provides a mechanical interlock and pre-wired reversing circuit.
Compliant with IEC, UL, CSA, CCC, EAC, and RoHS standards. Compact and DIN-rail compatible for easy installation. Suitable for industrial, manufacturing, and HVAC automation uses. Environmental design supports sustainability certifications.
Manufactured in France ensuring high-quality standards. Explore our electronics and electricals automation & control gear categories to find more Schneider Electric contactors and related components for your application needs.
Explore more products in our Automation & Control Gear category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this reversing contactor is 230V AC.
It supports a maximum contact voltage of 690V AC.
This model features 3 poles.
The contactor has a current rating of 6A.
The dimensions are 90mm in width, 58mm in length, and 57mm in depth.
The operational temperature range is from -25°C to 50°C.
It is equipped with screw terminal connections for secure wiring.
The contactor has a normal state configuration of 3 normally open (NO) contacts.
It complies with IEC, UL, CSA, CCC, EAC, and RoHS standards.
Yes, it is designed for DIN rail mounting, making installation easy.
This reversing contactor is designed for motor control and resistive load applications.
It can be complemented with auxiliary contact blocks and thermal relays for enhanced control and protection functionalities.
