HARWIN M22 Series Straight Through Hole PCB Socket, 16-Contact, 2 Row, 2 mm Pitch, 12A, 500V, Liquid Crystal M22-7140842
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M22-7140842 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Features a compact design suitable for high density PCBs.
- Constructed with liquid crystal polymer housing for high temperature resistance.
- Gold-plated bronze female contacts ensure reliable electrical connection.
- Maximum current rating of 12 Amps per contact and voltage rating of 500V.
- Supports up to 300 mating cycles for durability.
- Straight orientation with through-hole mount type for stable installation.
- Operating temperature range from -25°C to 105°C.
- Meets industrial requirements without additional certifications.
Product Description
HARWIN M22-7140842 is a high-quality, straight through hole PCB socket from the M22 Series, featuring 16 contacts arranged in 2 rows with a fine 2 mm pitch. Designed for board-to-board connectivity, this PCB socket offers a compact design that supports increased PCB density and height constraints.
The socket's housing is manufactured from UL94V-0 rated liquid crystal polymer, providing excellent thermal resistance compatible with reflow soldering processes. The female contacts are made of bronze and plated with gold, ensuring durable and reliable electrical connections. This socket supports a maximum current of 12 Amps per contact and a voltage rating of 500V, making it suitable for a wide range of electronic applications.
Designed to endure up to 300 mating cycles, the M22-7140842 socket guarantees longevity and robust performance. Its through-hole mounting and straight orientation provide mechanical stability, ideal for industrial, consumer electronics, communications, drives and controls, and embedded PC applications.
This solder termination type socket does not carry specific standards or approvals but is trusted for reliability in manufacturing and prototyping environments where high quality connectors are required.
HARWIN M22 series sockets are widely used in laboratory instrumentation, industrial monitoring, and personal computing applications, providing flexible and secure board-to-board connections.
Compact 2 mm pitch design for high-density PCB layouts. High temperature-resistant liquid crystal polymer housing. Gold-plated bronze contacts ensuring excellent conductivity and durability. Supports substantial current load of up to 12A per contact.
Long mating lifecycle with up to 300 cycles. Through hole mount for reliable mechanical fixing. Wide operating temperature range supporting varied industrial environments. Explore the wide range of HARWIN PCB Sockets and connectors on EnvMart to suit your specific electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M22-7140842 PCB socket has a maximum current rating of 12 Amps per contact.
This model is rated for a maximum voltage of 500V.
The contacts in this socket are arranged with a pitch size of 2 mm.
The M22-7140842 socket features 16 contacts arranged in 2 rows.
The housing is made from liquid crystal polymer, while the contacts are bronze plated with gold.
The operating temperature range for this socket is from -25°C to 105°C.
This socket uses a through-hole mount type for stable installation.
The termination type for this model is solder.
This socket is designed to support up to 300 mating cycles.
The M22-7140842 uses a board-to-board connector system.
This socket is suitable for applications in industrial, consumer electronics, communications, drives and controls, and embedded PCs.
The HARWIN M22-7140842 is manufactured in India.
