Murata Power Solutions DC/DC Converter 1W 5.5V Maximum Input Voltage 4.5V Minimum Input Voltage Through Hole DIP NME0505DC

Free Delivery in India | Lowest Global Shipping Charges

Murata Power Solutions DC/DC Converter 1W 5.5V Maximum Input Voltage 4.5V Minimum Input Voltage Through Hole DIP NME0505DC

Name: Murata Power Solutions DC/DC Converter 1W 5.5V Maximum Input Voltage 4.5V Minimum Input Voltage Through Hole DIP NME0505DC
Brand: Murata Power Solutions
SKU: 196807
Price: 9.24 USD
Availability: InStock



Category DC/DC Converter Brand Murata Power Solutions Condition New

Specifications

Country of Origin	India
Brand	Murata Power Solutions
Efficiency	69%
Length	11.5mm
Model	NME0505DC
Depth	6.8mm
Width	11.6mm
Mount Type	Through Hole
Series	NME
Maximum Operating Temperature	85°C
Package Type	DIP
Number of outputs	1
Maximum Output Power	1W
Maximum Input Voltage	5.5V dc
Standards/Approvals	RoHS
Minimum Input Voltage	4.5V
Output Voltage 1	4.5, 5.5V dc
Isolation Voltage	1kV dc

Key Features

The converter operates with 69% efficiency under typical conditions.
It features 1kV DC input/output isolation ensuring safe electrical separation.
RoHS compliant DIP8 plastic package with UL 94V-0 rated material.
Compact dimensions of 11.6mm width, 11.5mm length, and 6.8mm depth for space-sensitive applications.
Suitable for operating temperatures up to 85°C max, supporting reliable performance in industrial environments.
No external components are required for operation, simplifying system design.
MTBF tested to MIL-HDBK-217F at 25°C for dependable long-term usage.

Product Description

Murata Power Solutions NME0505DC is a high-efficiency, 1W DIP single output unregulated isolated DC/DC converter designed for applications requiring stable power conversion with minimal external circuitry. It accepts a DC input voltage range from 4.5V to 5.5V and delivers output voltages of 4.5V and 5.5V, isolated up to 1kV DC, making it ideal for industrial, electronic component, power supply, and transformer system use.

The robust through hole DIP8 plastic package is constructed with flame retardant UL 94V-0 material, complying with RoHS standards, thus ensuring safety and environmental compliance. Compact dimensions of 11.5mm length, 11.6mm width, and 6.8mm depth allow easy incorporation into space-restricted printed circuit boards.

This converter offers a 69% efficiency rate, providing reliable energy conversion while maintaining low heat dissipation. Its maximum operating temperature rating of 85°C ensures stable performance under elevated temperature conditions commonly encountered in industrial and power management settings.

The NME series converter is designed for easy integration without requiring additional external components, reducing design complexity and associated costs. It has been rigorously tested for mean time between failures (MTBF) in accordance with MIL-HDBK-217F standards at 25°C, providing confidence in durability and longevity.

The converter is ideal for use in electronic component design, power supplies, manufacturing automation, industrial instrumentation, and electrical panel systems. Its isolated output capability supports noise-sensitive environments and provides protection between input and output circuits.

The DIP package facilitates assembly with through hole mounting, suitable for prototype and production PCBs. Murata Power Solutions ensures product quality, backed by compliance certificates and technical documentation for application reliability.
