Sensata / Crydom CW Series Solid State Relay 50 A Load Panel Mount 660 V ac Load 36Vrms Control CWA4850E

Crydom CWA4850E Solid State Relay from the CW Series is a high-performance panel-mount relay suitable for controlling AC loads up to 50 A with a maximum load voltage of 660 V AC. It operates with a control voltage of 36 Vrms, providing reliable switching capabilities in industrial automation, electrical panels, and power control applications.

This relay features a single-pole single-throw (SPST) contact configuration, screw terminal connections for secure wiring, and zero voltage switching functionality to reduce electrical noise and increase load performance. Its robust design encompasses an operating temperature range from -40°C to 80°C, making it suitable for diverse environments.

The relay's compact form factor (45.7 mm length, 33 mm height, 22 mm width) enables ease of integration into panel boards while providing an integrated removable fingerproof cover enhancing safety for maintenance personnel. The SCR output and low off-state leakage current (1 mA) contribute to efficient operation and reduced power loss.

Engineered to meet CE and RoHS standards, the Crydom CW Series relay delivers compliance with international safety and environmental requirements. This product is ideal for use in industrial automation, HVAC systems, manufacturing process control, and electrical distribution panel applications requiring silent, durable, and maintenance-free relay control.

Supports a maximum load current of 50 A suitable for high power applications. Panel mount type enables easy and secure installation in control panels. Operates with a maximum load voltage of 660 V AC for versatile AC circuit control.

Equipped with screw type terminals ensuring reliable electrical connections. Boasts zero voltage switching function to minimize electrical noise and stress. Designed for operating temperatures from -40°C to 80°C for wide environmental tolerance.

Features SCR output type with low off-state leakage current of 1 mA for energy efficiency. Compact dimensions of 45.7 mm length, 33 mm height, and 22 mm width for space-saving installation. Includes an integrated removable fingerproof cover for operator safety.

Compliant with CE and RoHS standards ensuring quality and environmental safety. Explore more high-quality relays and electrical components at EnvMart for all your industrial automation needs.
