Amphenol Industrial EV Connector SURLOK PLUS RADSOK Female Panel Mount 300A 1000V SLPIRCBPSB1 / C10-730191-1101
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Straight |
| Current | 300A |
| Model | SLPIRCBPSB1 / C10-730191-1101 |
| Depth | 68.8mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 68.8mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Busbar |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 10.3mm |
| Number of Rows | 1 |
| Wire size | 70, 85mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
| Latch Type | Spring Locking |
Key Features
- Features a SURLOK PLUS RADSOK panel mount design for reliable busbar termination.
- Constructed with thermoplastic housing and copper alloy contacts for durability and conductivity.
- Includes spring locking latch and IP67 rating for environmental sealing.
- Compatible with 70mm² and 85mm² wire sizes and supports a maximum operating temperature of 125°C.
- Designed for use in electric vehicle, rail mass transit, process control, battery management, and heavy equipment applications.
- Keyed to prevent mismating with a 180-degree orientation and touch-proof construction.
- Complies with UL 94-V0 flammability standard ensuring safety and reliability.
- Compact size with 68.8mm width and depth and a 10.3mm pin diameter for secure connections.
Product Description
Amphenol Industrial SLPIRCBPSB1 / C10-730191-1101 EV Connector Female is an advanced electrical connector designed for demanding industrial and automotive applications requiring high current capacity and reliable performance. Rated at 300A and 1000V, this SURLOK PLUS RADSOK connector combines robust construction with easy panel mounting, utilizing a spring locking mechanism for secure and quick installation.
The connector features a thermoplastic housing and copper alloy contacts, ensuring excellent conductivity and durability under harsh environments. With an IP67 ingress protection rating, it is well suited for applications exposed to dust and moisture. The product supports wire sizes of 70 and 85mm² and withstands operating temperatures from -40°C to 125°C, making it suitable for extreme conditions.
This female connector includes a keyed design to prevent mismating and a touch-proof feature for enhanced safety. Its compact dimensions (68.8mm width and depth) and 10.3mm pin diameter enable reliable connections in tight spaces. The connector complies with the UL 94-V0 flammability standard, confirming its suitability for industrial and transportation electrical systems.
Typical uses include electric vehicles (EV/HEV), rail mass transit, process control applications, battery management systems, heavy machinery, and medical equipment. The panel mount flange design facilitates secure busbar termination with R4 Radsock technology, which guarantees a high tensile and highly conductive connection.
Amphenol Industrial's SURLOK PLUS range offers a dependable solution for renewable energy and heavy-duty applications, emphasizing environmental sustainability and operational safety. This connector is part of a family of products supporting advanced EV charging, battery storage, and industrial control systems.
Features a SURLOK PLUS RADSOK panel mount design for reliable busbar termination. Constructed with thermoplastic housing and copper alloy contacts for durability and conductivity. Includes spring locking latch and IP67 rating for environmental sealing.
Compatible with 70mm² and 85mm² wire sizes and supports a maximum operating temperature of 125°C. Designed for use in electric vehicle, rail mass transit, process control, battery management, and heavy equipment applications.
Keyed to prevent mismating with a 180-degree orientation and touch-proof construction. Complies with UL 94-V0 flammability standard ensuring safety and reliability. Compact size with 68.8mm width and depth and a 10.3mm pin diameter for secure connections.
Explore more products from Amphenol Industrial and browse the EV Connectors category on EnvMart for related high-performance connectors and accessories tailored to industrial and automotive electrification needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 300A.
It supports a maximum operating voltage of 1000V.
This unit is compatible with wire sizes of 70mm² and 85mm².
It has an IP67 rating, providing protection against dust and moisture.
The connector can operate within a temperature range of -40°C to 125°C.
It features a thermoplastic housing and copper alloy contacts for durability and conductivity.
It includes a keyed design with a 180-degree orientation to prevent mismating.
This model utilizes a panel mount design for secure installation.
The pin diameter is 10.3mm, allowing for secure connections.
It is designed for use in electric vehicles, rail mass transit, process control, battery management, and heavy equipment applications.
It complies with the UL 94-V0 flammability standard, ensuring safety and reliability.
It includes a spring locking latch for secure and quick installation.
