Eaton xEffect Miniature Circuit Breaker, 2-Pole, 20A, Type S, 230V AC, 10 kA Breaking Capacity 278812 FAZ-S20/2

Eaton 278812 FAZ-S20/2 Miniature Circuit Breaker is a high-quality protection device designed for electrical distribution and control systems operating at 230V AC with a current rating of 20A and a breaking capacity of 10 kA. Part of Eaton's xEffect range, this MCB provides both thermal and electromagnetic release mechanisms for reliable and fast protection against overloads and short circuits.

The compact 2-pole device mounts easily on DIN rails with a slim 35mm width, saving panel space. It features a twin-purpose terminal type and a toggle switch for convenient resetting. The instantaneous break time and Type S tripping characteristics ensure precise fault detection and quick disconnection, protecting both equipment and personnel.

The breaker is finger proof and includes a trip-free mechanism preventing manual override for added safety. Compliance with IEC 60947-2 standards ensures suitability for industrial and similar installations.

Thermal-magnetic overcurrent protection safeguards circuits effectively. Compact 35mm width allows efficient panel installation. Type S tripping characteristic provides a specific protection curve. Twin-purpose terminal enhances wiring versatility.

Instantaneous break time ensures fast circuit interruption. IP20 protection offers finger-safe operation. Modular width of 17.5mm per pole for space efficiency. Robust design suitable for control and distribution boards.

Suitable for industrial applications requiring reliable circuit protection.

Commonly used in industrial, manufacturing, electrical, commercial, and HVAC electrical protection systems, this Eaton MCB is integral to ensuring electrical safety and compliance. For more electrical circuit protection solutions, explore the extensive Eaton product line and related categories in the EnvMart catalog.
