Relpol PCB Power Relay 12V DC Coil 16A Switching Current SPDT RM85-2011-35-1012

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 12V DC Coil 16A Switching Current SPDT RM85-2011-35-1012

Name: Relpol PCB Power Relay 12V DC Coil 16A Switching Current SPDT RM85-2011-35-1012
Brand: Relpol
SKU: 191751
Price: 4.84 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	15.7mm
Length	29mm
Model	RM85-2011-35-1012
Width	12.7mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM85
Maximum Operating Temperature	85°C
Contact Configuration	SPDT
Minimum Operating Temperature	-40°C
Switching Current	16A
Terminal type	Plug-In
Contact Resistance	100mΩ
Standards/Approvals	RoHS, EAC
Coil Resistance	360Ω
Coil Voltage	12V dc
Switching DC Voltage	24V dc
Switching AC Voltage	440V
Coil Power	480mW

Key Features

Supports a coil voltage of 12V DC for efficient operation.
Features Single Pole Double Throw (SPDT) contact configuration.
Designed for PCB mounting with a plug-in terminal type.
Capable of switching 16A current with a maximum switching power of 4kVA.
Operates reliably within temperature range from -40°C to 85°C.
Compact dimensions with length 29mm, width 12.7mm, and height 15.7mm.
Utilizes silver alloy contact material to ensure durability and low contact resistance of 100mΩ.
Coil resistance is 360Ω and coil power consumption is 480mW.

Product Description

Relpol RM85-2011-35-1012 is a high-quality PCB power relay designed for general purpose industrial applications. The relay features a 12V DC coil voltage and supports a switching current of 16A with SPDT (Single Pole Double Throw) contact configuration. Its compact design and plug-in terminal type make it ideal for PCB mounting in industrial electrical circuits.

This relay offers robust electrical switching capabilities, handling up to 4kVA of power, suitable for both AC (up to 440V) and DC (up to 24V) voltages. The coil resistance of 360Ω and coil power of 480mW ensure efficient coil operation with minimal power consumption.

Constructed with silver alloy contacts, it ensures durable performance and low contact resistance (100mΩ), critical for reliable operation in demanding environments. It operates reliably over a wide temperature range from -40°C to 85°C, accommodating harsh industrial conditions.

The compact physical dimensions of length 29mm, width 12.7mm, and height 15.7mm allow for space-conscious PCB designs. Additionally, the relay complies with RoHS and EAC standards, reflecting its environmental safety and quality.

Typical industrial use includes electrical control systems, automation, instrumentation, and signal conditioning circuits. The plug-in design simplifies installation and maintenance, enabling quick replacement when required.

Supports a coil voltage of 12V DC for efficient operation. Features Single Pole Double Throw (SPDT) contact configuration. Designed for PCB mounting with a plug-in terminal type. Capable of switching 16A current with a maximum switching power of 4kVA.

Operates reliably within temperature range from -40°C to 85°C. Compact dimensions with length 29mm, width 12.7mm, and height 15.7mm. Utilizes silver alloy contact material to ensure durability and low contact resistance of 100mΩ.

Coil resistance is 360Ω and coil power consumption is 480mW. Suitable for AC voltage switching up to 440V and DC voltage switching up to 24V DC. Complies with RoHS and EAC standards for environmental and safety requirements.
