Baumer BDK Series Optical Incremental Encoder 30V dc, 360 PPR, HTL/Push Pull Signal, Solid Shaft 6 mm BHK 16.24K360-B6-5

Free Delivery in India | Lowest Global Shipping Charges

Baumer BDK Series Optical Incremental Encoder 30V dc, 360 PPR, HTL/Push Pull Signal, Solid Shaft 6 mm BHK 16.24K360-B6-5

Name: Baumer BDK Series Optical Incremental Encoder 30V dc, 360 PPR, HTL/Push Pull Signal, Solid Shaft 6 mm BHK 16.24K360-B6-5
Brand: Baumer
SKU: 191445
Price: 696.4 USD
Availability: InStock



Category Incremental Encoder Brand Baumer Condition New

Specifications

Country of Origin	Switzerland
Brand	Baumer
Model	BHK 16.24K360-B6-5
IP Rating	IP42
Mount Type	Synchro Flange Mount
Series	BDK
Overall Width	30mm
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-20°C
Shaft Diameter	6mm
Switching Frequency	100kHz
Shaft Type	Solid
Terminal type	1 m Cable
Interface Type	TTL
Pulses per Revolution	360ppr
Standards/Approvals	UL
Maximum Supply Voltage	30V dc
Overall Depth	34mm
Encoder Technology	Optical
Maximum Revolutions	12000rpm
Output Signal Type	HTL/Push Pull

Key Features

This encoder supports a maximum speed of 12000 rpm.
The output signal type is HTL/Push Pull for reliable signal transmission.
It features a synchro flange mount and a 1 m cable terminal type.
The solid shaft diameter measures 6 mm, with an overall depth of 34 mm and width of 30 mm.
The device operates within a temperature range of -20°C to 85°C.
It holds an IP42 ingress protection rating for moderate protection against dust and liquids.
The maximum supply voltage is 30V dc, maintaining efficient and stable operation.
Equipped with a switching frequency of 100 kHz for rapid signal changes.

Product Description

Baumer BHK 16.24K360-B6-5 is an optical Incremental Encoder from the BDK series, designed for precision motion control applications. Operating at 30V dc with 360 pulses per revolution, this encoder provides accurate position feedback for industrial automation and control systems.

The encoder incorporates a solid 6 mm shaft and uses HTL/Push Pull output signals, ensuring high signal integrity and compatibility with modern controllers. It supports a maximum rotational speed of 12000 rpm, making it suitable for fast moving machinery.

Its mechanical design includes a synchro flange mount and robust plastic housing with an aluminium flange, facilitating easy installation and durable protection. The device features a 1 meter cable for connectivity and is rated IP42 for dust and splash resistance.

Operating temperature ranges from -20°C to 85°C, allowing reliable performance in various industrial environments. The switching frequency is rated at 100 kHz, accommodating rapid signal processing requirements.

This encoder is ideal for applications in industrial automation, motion control, robotics, and manufacturing processes where precise shaft position measurement is critical. Its Swiss origin assures high manufacturing quality and reliability.

This encoder supports high-speed operation up to 12000 rpm. HTL/Push Pull signals ensure noise-resistant output. Solid 6 mm shaft with synchro flange mount offers reliable mechanical coupling. Durable plastic housing with aluminium flange ensures long-term stability.

IP42 rating provides moderate dust and splash protection. Wide operating temperature range enhances environmental adaptability. 1 m cable terminal facilitates flexible connectivity options. 100 kHz switching frequency for fast signal changes.

Manufactured in Switzerland with strict quality controls. Compact dimensions with 34 mm depth and 30 mm width support space-constrained installations. Explore Baumer sensors and encoders at EnvMart for advanced industrial automation solutions.
