TE Connectivity 9 Way Right Angle 2.74 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock Female 3-106505-2
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 1kV |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 6A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | 106505 |
| Mounting Hardware | 4 to 40 UNC Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.74mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector Gender | Female |
Key Features
- The connector offers 9 electrical contacts supporting a current rating of 6 amperes.
- It has a fibreglass reinforced polyethylene terephthalate housing for durability.
- Operates reliably within a temperature range of -55°C to 105°C.
- Phosphor bronze contacts plated with gold over nickel ensure excellent conductivity and corrosion resistance.
- Designed for through-hole mounting with solder termination and integrated PCB mounting and earthing.
- Complies with DIN 41652 standards providing a European standard footprint.
- Metal cover with screw lock UNC 4-40 internal thread provides mechanical security.
- Suitable for industrial, electronic component assembly, and power connector applications.
Product Description
TE Connectivity 3-106505-2 is a 9 Way Right Angle Through Hole D-Sub Connector with a 2.74 mm pitch and female contact gender. Manufactured with a fibreglass reinforced polyethylene terephthalate housing and phosphor bronze contacts plated with gold over nickel, this connector ensures reliable electrical performance at up to 6 amperes current and 1 kV voltage rating. The connector features 4 to 40 UNC screw lock mounting hardware and is designed for solder termination enabling secure and durable connections.
This connector supports a temperature range from -55°C to 105°C, making it well suited for use in harsh industrial environments and electronic assemblies requiring robust and stable connectivity. Its metal cover provides additional mechanical protection and earthing via integrated PCB mounting, conforming to DIN 41652 standards with a European standard footprint.
The 3-106505-2 connector is ideal for industrial applications in manufacturing, electronic instrumentation, power connectors, and PCB assemblies where high reliability and performance are critical.
The connector provides reliable 9-way electrical contacts supporting 6A current. Housing material offers excellent mechanical stability with heat resistance. Gold over nickel plating provides superior corrosion resistance and contact integrity.
Right angle orientation facilitates compact PCB designs and wiring solutions. Screw lock mounting ensures secure connections in vibration-prone environments. Operates effectively across wide temperature extremes from -55°C to 105°C.
Suitable for through-hole mounting with solder termination technology.
This TE Connectivity D-Sub Connector supports electronic and power interconnectivity needs in industries such as telecommunications, industrial automation, computing, and instrumentation. It enhances production efficiency by allowing ready insertion into machinery and durable connection interfaces.
Explore more connectors and components in the Electronics & Electricals section on EnvMart for a comprehensive range of high-quality industrial-grade products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector supports a current rating of 6 amperes.
It has a voltage rating of 1 kV.
It operates reliably within a temperature range of -55°C to 105°C.
The housing is made from fibreglass reinforced polyethylene terephthalate, and the contacts are phosphor bronze plated with gold over nickel.
It is designed for through-hole mounting with solder termination.
It uses 4 to 40 UNC screw lock mounting hardware.
This model features a right angle orientation.
It has 9 electrical contacts.
It complies with DIN 41652 standards, providing a European standard footprint.
It is suitable for industrial applications, electronic component assembly, and power connector applications.
The pitch of this connector is 2.74 mm.
The country of origin for this connector is Poland.
