Gefran PY2 Series Linear Transducer Connector 25V F004199/ PY-2-C-025 0000X000X00

Gefran F004199/ PY-2-C-025 0000X000X00 linear transducer connector operates at a maximum supply voltage of 25V, designed to provide reliable and precise linear position feedback for automation and control applications. This device features a durable construction with anodised aluminium and Polyamide 66 housing materials, making it suitable for industrial environments.

The product has an overall depth of 29 mm, height of 41 mm, and width of 138 mm, facilitating easy integration into existing systems. The connector complies with CE and RoHS standards, ensuring safety and environmental compliance.

The transducer offers 25 mm stroke length with a double support control rod and return spring assembly, increasing mechanical stability and precise operation. Its tip is equipped with an M2.5 threaded stainless steel bearing, enhancing durability and accuracy.

Performance specifications include an independent linearity of ±0.1%, infinite resolution, and no electrical signal variations outside the theoretical electrical stroke. It supports a maximum displacement speed of 10 m/s, suitable for high-speed applications. The transducer maintains optimum functionality within a temperature range of -30°C to 100°C and holds an IP40 rating for protection against solid particles.

With a guaranteed life duration of over 100 million operations within the CEU, this linear transducer connector is built for long-term use in demanding industrial, automation, manufacturing, and motion control sensor setups.

Equipped with a 25 mm stroke for fine measurement accuracy. Double support of the control rod and return spring for durability. Tip with M2.5 thread and stainless steel bearing for mechanical stability. Independent linearity maintained up to ±0.1% for high precision.

Infinite resolution with no output signal variation outside theoretical stroke. Maximum displacement speed up to 10 m/s for dynamic use. Operating temperature range from -30° to 100°C suitable for harsh environments. Robust anodised aluminium and Polyamide 66 housing construction.

5-pole electrical connector with IP40 dust protection rating. Life duration over 100 million operations within CEU for long-term reliability.

This Gefran linear transducer connector is ideally suited for applications in industrial automation, motion control sensors, manufacturing lines, and process control systems requiring accurate linear displacement measurement. Explore more products in the Linear Transducer category to find compatible sensors and connectors for your technical needs.
