Nexperia 1.47 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount SOD-80 BZV55-C47,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.47 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount SOD-80 BZV55-C47,115

Name: Nexperia 1.47 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount SOD-80 BZV55-C47,115
Brand: Nexperia
SKU: 180635
Price: 20.22 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BZV55-C47,115
Mount Type	Surface
Series	BZV55
Maximum Operating Temperature	200°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	2mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	47V
Zener Type	Voltage Regulator
Maximum Zener Impedance	170Ω
Typical Voltage Temperature Coefficient	42.9mV/°C

Key Features

This device features a surface mount SOD-80 package for efficient PCB integration.
It offers a 5% voltage tolerance ensuring stable voltage regulation performance.
The maximum Zener impedance is 170 Ohms, supporting effective voltage regulation.
Operating temperature range extends from -65°C to 200°C for broad application versatility.
The diode has low leakage current of up to 50 nA to minimize power loss.
The 2-pin configuration simplifies circuit design and mounting.
Typical voltage temperature coefficient is 42.9 mV/°C for predictable temperature behavior.
Ideal for use as a voltage regulator in electronic and industrial applications.

Product Description

Nexperia BZV55-C47,115 is a Zener diode designed for voltage regulation tasks in electronic circuits. It operates with a nominal Zener voltage of 1.47 V and can safely dissipate power up to 500 mW. This single element diode comes in a compact SOD-80 surface mount package, suitable for automated PCB assembly.

The diode offers a tight voltage tolerance of ±5%, ensuring reliable and consistent voltage regulation. Its maximum Zener impedance of 170 Ohms supports stable performance under test current conditions of 2 mA.

With a broad operating temperature range from -65°C to 200°C, this component is suitable for rugged industrial and commercial applications. The low maximum reverse leakage current of 50 nA enhances energy efficiency and minimizes leakage losses in circuits.

The physical dimensions of the diode include a length of 3.7 mm and a height of 1.6 mm, optimized for space-efficient PCB layouts. The device is part of the BZV55 series from Nexperia and features a typical voltage temperature coefficient of 42.9 mV/°C for predictable thermal stability.

This Zener diode is ideal for use in power supply regulation, voltage reference, and protection circuits in industrial, manufacturing, laboratory, and commercial electronic equipment design.

This device features a surface mount SOD-80 package for efficient PCB integration. It offers a 5% voltage tolerance ensuring stable voltage regulation performance. The maximum Zener impedance is 170 Ohms, supporting effective voltage regulation.

Operating temperature range extends from -65°C to 200°C for broad application versatility. The diode has low leakage current of up to 50 nA to minimize power loss. The 2-pin configuration simplifies circuit design and mounting.

Typical voltage temperature coefficient is 42.9 mV/°C for predictable temperature behavior. Ideal for use as a voltage regulator in electronic and industrial applications.

Explore more semiconductor and discrete electronic components in the EnvMart catalog, including comprehensive options for Zener Diodes suitable for your industrial and laboratory needs.
