Bartec Plunger Limit Switch, 1 NO/1 NC, IP66, Plastic Housing, 400V AC, 2A IP66

Free Delivery in India | Lowest Global Shipping Charges

Bartec Plunger Limit Switch, 1 NO/1 NC, IP66, Plastic Housing, 400V AC, 2A IP66

Name: Bartec Plunger Limit Switch, 1 NO/1 NC, IP66, Plastic Housing, 400V AC, 2A IP66
Brand: Bartec
SKU: 180174
Price: 169.81 USD
Availability: InStock



Category Limit Switch Brand Bartec Condition New

Specifications

Country of Origin	Germany
Brand	Bartec
Length	46.2mm
Model	IP66
Depth	15.8mm
IP Rating	IP66
Width	25.5mm
Housing Material	Plastic
Maximum Operating Temperature	40°C
Contact Configuration	1 NO/1 NC
Actuator Type	Plunger
Contact Type	Snap Action
Minimum Operating Temperature	-20°C
Switching Current	2A
Hazardous Area Certification	ATEX
Standards/Approvals	IEC, EN, RoHS
Mechanical Life	2000000Cycles
Switching DC Voltage	250V dc
Switching AC Voltage	400V ac
Bartec Plunger Limit Switch, 1 NO/1 NC, IP66, Plastic Housing, 400V ac, 2ABrand	Bartec

Key Features

This limit switch features a plunger actuator type for precise control.
Equipped with snap action contacts configured as 1 normally open and 1 normally closed.
Constructed with a durable plastic housing offering IP66 ingress protection.
Operates at a switching current of 2A with 400V AC voltage rating.
Suitable for temperatures ranging from -20°C to 40°C for versatile industrial usage.
Compact dimensions measuring 46.2 mm length, 25.5 mm width, and 15.8 mm depth.
Certified to IEC, EN, RoHS standards and compliant with ATEX hazardous area certification.
Designed for high reliability with a mechanical life expectancy of 2,000,000 cycles.

Product Description

Bartec IP66 Plunger Limit Switch 1 NO/1 NC is engineered for demanding mechanical engineering applications requiring secure and reliable signalling. Its snap-action contact switching element offers dependable performance for control and safety systems operating at 400V AC and rated switching current of 2A. The actuator is a plunger type designed to provide positive engagement with a 0.3 mm break distance for stable contact changeover.

The robust plastic housing ensures IP66 protection against dust and water ingress, making this limit switch suitable for harsh industrial environments. Operating temperature range from -20°C to 40°C broadens the scope of use in diverse conditions.

This device meets international standards including IEC, EN, and RoHS certifications, along with ATEX hazardous area certification, affirming its suitability for explosive environments. The mechanical durability is outstanding with an expected life of 2 million operational cycles.

Its compact form factor with dimensions of 46.2mm x 25.5mm x 15.8mm allows installation flexibility within control panels and machinery parts. The package includes a 3 meter connecting cable for easy integration.

This limit switch features a plunger actuator type for precise control. Equipped with snap action contacts configured as 1 normally open and 1 normally closed. Constructed with a durable plastic housing offering IP66 ingress protection.

Operates at a switching current of 2A with 400V AC voltage rating. Suitable for temperatures ranging from -20°C to 40°C for versatile industrial usage. Compact dimensions measuring 46.2 mm length, 25.5 mm width, and 15.8 mm depth.

Certified to IEC, EN, RoHS standards and compliant with ATEX hazardous area certification. Designed for high reliability with a mechanical life expectancy of 2,000,000 cycles. Includes a 3 meter connecting cable for flexible installation.

Made in Germany ensuring quality and precision manufacturing.

This Bartec Limit Switch is ideal for industrial automation, machinery safety systems, process control, and hazardous area signalling applications. Explore more products in our Electronics & Electricals category for comprehensive automation solutions.
