Renesas Electronics Line Transceiver 3 State Bipolar 8-Pin SOIC ISL81487IBZ-T

Free Delivery in India | Lowest Global Shipping Charges

Renesas Electronics Line Transceiver 3 State Bipolar 8-Pin SOIC ISL81487IBZ-T

Name: Renesas Electronics Line Transceiver 3 State Bipolar 8-Pin SOIC ISL81487IBZ-T
Brand: Renesas Electronics
SKU: 174858
Price: 0.88 USD
Availability: InStock



Category Electronics Components Brand Renesas Electronics Condition New

Specifications

Country of Origin	India
Brand	Renesas Electronics
Height	1.75mm
Length	5mm
Model	ISL81487IBZ-T
Width	6.2mm
Mount Type	Surface
Output type	3 State
Series	ISL81487
Input Type	Differential
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Polarity	Bipolar
IC Type	Line Transceiver
Pin Count	8
Maximum Supply Voltage	12V
Logic Family	CMOS
Logic Function	Transceiver
Minimum Supply Voltage	-7V
Maximum High Level Output Current	-4mA
Maximum Propagation Delay Time @ CL	30ns
Supply Current	500μA

Key Features

Supports both RS-485 and RS-422 balanced communication standards.
3 state bipolar output design for robust signal control.
Minimum supply voltage of -7V and maximum of 12V to support various power requirements.
Low supply current consumption of 500μA for energy-efficient operation.
Wide operating temperature range from -40°C to 85°C suitable for harsh environments.
Compact 8-pin SOIC surface mount package with precise dimensions.
Fractional unit load allows connection of up to 256 devices on the bus.
Maximum propagation delay time of 30 nanoseconds for fast data transmission.

Product Description

Renesas Electronics ISL81487IBZ-T is a highly reliable line transceiver designed for half duplex RS-485 and RS-422 balanced communication systems. Packaged in a compact 8-pin SOIC surface mount form, this device meets the standards required for robust industrial and commercial electronic assembly.

This transceiver incorporates a 3 state output and bipolar logic polarity, which ensures compatibility with a broad range of interface applications. It is designed to operate efficiently with supply voltages ranging from -7V to 12V and features an ultra-low supply current of 500μA, making it an energy-efficient choice for system designers.

Operational across a wide temperature range from -40°C to 85°C, the ISL81487IBZ-T supports demanding industrial environments. Its fractional unit load capability allows up to 256 devices to be connected on a single bus, facilitating extensive networking possibilities.

The device has a maximum propagation delay time of 30 nanoseconds at specified load conditions, guaranteeing fast and reliable signal transmission for time-critical applications. This transceiver supports both RS-485 and RS-422 communication standards.

Three-state bipolar output enhances signal integrity and line control. Energy-efficient operation with low supply current of 500μA. Wide operating temperature range for versatile industrial use. Compact SOIC 8-pin surface mount package simplifies PCB design.

Fractional unit load allows extensive network connection with up to 256 devices. Maximum propagation delay time of 30ns ensures rapid data handling.

The ISL81487IBZ-T line transceiver is ideal for industrial automation, data communication networks, and control systems requiring reliable, low power, and high-speed interface ICs. With extensive use cases ranging from manufacturing to commercial electronic assemblies, this device suits various design and operational challenges.

Explore more semiconductor and line interface IC solutions in EnvMart's Electronics Components category for advanced industrial and electronic applications.
