Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header 9 Contacts 2.54 mm Pitch 1 77311-118-09LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 77311-118-09LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 130°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | UL Approval:E66906 |
| Contact Plating | Phosphor Bronze |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
| Standards/ApprovalsUL Approval | E66906 |
| UL Approval | E66906 |
Key Features
- Unshrouded vertical orientation allows easy soldering and connection.
- Constructed with thermoplastic housing for high temperature resilience.
- Phosphor bronze contacts and plating ensure reliable conductivity and corrosion resistance.
- Rated for 3A current and up to 1500V voltage operating conditions.
- Supports solder termination and through-hole mounting for sturdy PCB attachment.
- Compact 2.54 mm pitch with 1 row and 9 contacts suits mezzanine applications.
- Wide operating temperature range from -65°C to 130°C for diverse environments.
- UL Approval (E66906) certifies compliance with safety standards.
Product Description
Amphenol Communications Solutions 77311-118-09LF Bergstik Series vertical through hole pin header is engineered to provide reliable board-to-board connection in electronic assemblies. Featuring a 2.54 mm pitch and single row configuration with 9 male contacts, this pin header is designed for applications requiring robust electrical connectivity and mechanical stability.
The header's housing is made from high temperature thermoplastic material, making it suitable for demanding industrial and automotive environments where heat resistance is critical. The phosphor bronze contact material and plating provide excellent electrical conductivity and corrosion resistance, ensuring long life and dependable performance.
This 3A rated connector accommodates up to 1500V operation, making it ideal for power and signal applications on PCBs. The unshrouded design facilitates easy solder termination of the tail pins, which measure 3.05 mm in length, while the mating pin length of 5.84 mm ensures secure connection with complementary components.
The vertical orientation and through-hole mounting style make this pin header suitable for mezzanine and stacked board assemblies, offering flexibility in PCB layout design. It meets UL approval (E66906), underscoring its compliance with industry safety standards.
Designed and manufactured in France, this Bergstik Series pin header promises premium build quality. It is widely used in industrial automation, telecommunications, instrumentation, and other electronic manufacturing sectors requiring consistent, high-quality PCB interconnect solutions.
Unshrouded vertical 1-row pin header with 9 contacts. 2.54 mm pitch with through-hole mounting for robust assembly. Thermoplastic housing suitable for high temperature environments. Phosphor bronze contact and plating ensure durable conductivity.
Current rating of 3A and voltage rating of 1500V for versatile use. Tail pin length 3.05 mm and mating pin length 5.84 mm. Wide operating temperature range from -65°C to 130°C. UL approved (E66906) for safety assurance. Manufactured in France to high quality standards.
Explore a wide selection of PCB Headers and connectors at EnvMart to meet your electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header is rated for a current of 3A.
It has a voltage rating of up to 1500V.
The pitch size of this pin header is 2.54 mm.
This model features 9 male contacts.
The housing is made from thermoplastic, and the contacts are made of phosphor bronze with phosphor bronze plating.
It operates within a temperature range of -65°C to 130°C.
This model supports solder termination.
The tail pin length is 3.05 mm.
The mating pin length is 5.84 mm.
It features a through-hole mounting style.
Yes, it has UL approval (E66906), certifying its compliance with safety standards.
This pin header is manufactured in France.
