Amphenol Air LB Circular Connector, 4 Contacts, Push Pull Mount, Socket Male, IP66 IP67 Rated, Standard Size 1331EV295MS

Amphenol Air LB 1331EV295MS Circular Connector is a high-performance industrial circular connector designed for applications requiring reliable electrical connections under harsh environmental conditions. It features a rugged metal housing with a push pull locking system and male socket contact configuration.

With 4 copper contacts plated with gold over nickel, it ensures excellent conductivity and corrosion resistance, supporting current ratings up to 13A and voltages up to 800V. The connector is suitable for use in extreme temperatures ranging from -40°C to +125°C, ideal for industrial, manufacturing, HVAC, and electronic system applications.

This connector is designed according to the ECTA 133 series specifications, offering a standard shell size of 2 mm and a straight orientation for straightforward installations. It provides a high level of ingress protection with IP66 and IP67 ratings, protecting against dust and temporary water immersion, making it suited for demanding environmental conditions.

The push pull termination and mounting system enable quick and secure mating and demating operations, designed to endure 1000 mating cycles, ensuring longevity and reliability in industrial use cases. This product is made in Germany, reflecting stringent manufacturing quality.

Constructed with metal housing for robust mechanical protection. Supports operating voltages up to 800V and currents up to 13A. Features gold over nickel plated copper contacts for superior conductivity and corrosion resistance.

Operates in temperature ranges from -40°C to +125°C ensuring wide environmental usability. Push pull locking mechanism allows quick and secure mating operations. Standard connector size with 2 mm shell size for compatibility.

Designed to withstand 1000 mating operations for long service life. Maintains IP66 and IP67 ingress protection ratings against dust and water ingress. Manufactured in Germany adhering to quality standards without specific certifications.

This Amphenol Air LB connector series targets industrial, electronic component assembly, power distribution, and HVAC systems demanding high reliability and environmental resistance. For a broader range, explore related Industrial Circular Connectors at EnvMart.
