OEP Through Hole Pulse Transformer 1:1+1 Turns Ratio, 3 mH Primary Inductance, 1.4Ω Primary Resistance PT6E

OEP PT6E Through Hole Pulse Transformer 1:1+1 Turns Ratio is a high-quality pulse transformer designed for electronics applications requiring reliable isolation and precise pulse handling. Featuring a primary inductance of 3 mH and a primary resistance of 1.4 ohms, this transformer ensures efficient signal transfer within electronic circuits.

The device supports a broad operating frequency range from 3 kHz to 1 MHz, making it suitable for pulse and switching applications, particularly in thyristor and triac control systems. Its through-hole mount design facilitates robust PCB assembly and mechanical stability during operation.

With physical dimensions of 15 mm in length and width, and 16 mm in depth, the compact size supports applications in space-constrained environments. The secondary DC resistance of 2.6 ohms ensures consistent performance under load conditions.

Manufactured in China, the PT6E transformer conforms to quality standards though without specific certifications. Applications include industrial automation, power supply design, pulse modulation systems, and other electronics requiring precise transformer characteristics and effective electrical isolation.

Designed for through-hole PCB mounting providing durability. Primary inductance of 3 mH offers suitable energy storage for pulse applications. Primary and secondary DC resistances support efficient electrical conduction.

Wide frequency operating range ensures versatility in electronic use cases. Compact dimensions accommodate integration into smaller circuit boards. Ideal for controlling thyristors, triacs, and related pulse equipment. Manufactured in China ensuring consistent production quality.
