OEP Through Hole Pulse Transformer 2:1 Turns Ratio, 115 μH Primary Inductance, 5.10Ω Primary Resistance PT10

OEP PT10 Through Hole Pulse Transformer offers a reliable 2:1 turns ratio, 115 μH primary inductance, and 5.10Ω primary resistance. It is specially designed for use in high-frequency pulse transformer applications with a through-hole mount type suitable for PCB installations. These transformers provide essential isolation between firing circuits and loads, making them ideal for thyristor and triac control systems in industrial electronics.

With a compact form factor measuring 13 mm in length, 13 mm in width, and 15 mm in depth, this transformer is engineered for efficient mounting and operation within diverse electronic devices. It supports a wide operating frequency range from 3 kHz to 1 MHz, ensuring its adaptability to various pulse system requirements.

Constructed to fulfill demanding operational and environmental conditions, this pulse transformer is built without specific certifications but adheres to reliable manufacturing standards. Its primary and secondary resistances - 5.10Ω and 2.6Ω respectively - contribute to its efficiency in signal rise time and pulse integrity.

This product is suitable for use in industrial electronics, power supplies, manufacturing control systems, and electronic instrumentation within laboratory and commercial environments. The proven design ensures dependable performance in sensitive electronic circuits requiring isolation and signal transformation.

The transformer provides a 2:1 turns ratio ensuring effective signal transformation. Primary inductance is rated at 115 microhenries for optimized electrical performance. Primary DC resistance measures 5.10 ohms, ensuring minimal power loss.

Operates effectively in the frequency range from 3 kHz up to 1 MHz. Constructed for through-hole PCB mounting with 13 mm length, 13 mm width, and 15 mm depth dimensions. Suitable for high-frequency pulse applications including thyristor and triac control systems.

Manufactured in China under brand OEP maintaining quality and consistency. Reliable isolation between firing circuits and loads is provided by the transformer design. Explore EnvMart for a wide range of Pulse Transformers and related electronic components from trusted brands like OEP to meet your industrial and electronic engineering needs.
