Murata Power Solutions Through Hole Pulse Transformer 3:71 Turns Ratio, 4000 μH Primary Inductance, 0.92Ω Primary 78602/16C

Free Delivery in India | Lowest Global Shipping Charges

Murata Power Solutions Through Hole Pulse Transformer 3:71 Turns Ratio, 4000 μH Primary Inductance, 0.92Ω Primary 78602/16C

Name: Murata Power Solutions Through Hole Pulse Transformer 3:71 Turns Ratio, 4000 μH Primary Inductance, 0.92Ω Primary 78602/16C
Brand: Murata Power Solutions
SKU: 103067



Category Pulse Transformer Brand Murata Power Solutions Condition New

Specifications

Country of Origin	China
Brand	Murata Power Solutions
Length	9.52mm
Model	78602/16C
Depth	6.35mm
Gross Weight	1.1g
Width	9mm
Mount Type	Through Hole
Series	786
Termination Type	Pin
Maximum Operating Temperature	70°C
Minimum Operating Temperature	0°C
Standards/Approvals	RoHS
Number of Pins	6
Isolation Voltage	1kV
Primary Inductance	4000μH
Turns Ratio	3:71
Primary DC Resistance	0.92Ω
Leakage Inductance	0.71μH
Turns Ratio3	71

Key Features

Primary inductance of 4000 microhenries ensures stable energy transfer.
Low primary DC resistance of 0.92 ohms minimizes power loss.
Six-pin through hole mount type for reliable PCB mounting.
Leakage inductance as low as 0.71 microhenry enhancing performance.
Operating temperature range from 0°C to 70°C supports industrial environments.
Isolation voltage rated at 1 kilovolt for safety and insulation.
RoHS compliant, ensuring environmentally friendly manufacturing.
Manufactured in China to strict quality standards.

Product Description

Murata Power Solutions 78602/16C through hole pulse transformer features a precise 3:71 turns ratio and 4000 μH primary inductance, suitable for industrial, electronic, and power supply applications. Its primary DC resistance is 0.92Ω, providing efficient energy transfer in thyristor/triac firing circuits and switch mode power supplies.

The six-pin through hole mount design ensures stable PCB integration, while a leakage inductance of 0.71 μH minimizes signal loss. Operating temperatures from 0°C to 70°C allow this transformer to perform reliably in moderate industrial environments.

Compact in size with dimensions of 9.52 mm (length), 9 mm (width), and 6.35 mm (depth), it supports space-constrained applications. The product meets RoHS standards reducing hazardous substances and is rated for 1 kV isolation voltage, ensuring electrical safety.

Primary inductance of 4000 μH for reliable pulse transformation. Low primary DC resistance of 0.92Ω reduces power dissipation. Six pins facilitate secure through hole mounting on PCBs. Leakage inductance of 0.71 μH enhances signal integrity.

Temperature range of 0°C to 70°C for versatility in use. Compact dimensions allow compact PCB layouts. 1 kV isolation voltage ensures compliance with safety norms. RoHS compliance supports environmentally responsible usage.

Manufactured in China with consistent quality control.

This pulse transformer is ideal for industrial machinery, laboratory equipment, and electronic power supplies requiring precise pulse control. It meets the demands of power supply designers and engineers for efficient and reliable transformer components.
