Turck LRS510 Series Radar Level Sensor, Stainless Steel Housing, Polyetheretherketone Gasket, IO-Link, Model

Free Delivery in India | Lowest Global Shipping Charges

Turck LRS510 Series Radar Level Sensor, Stainless Steel Housing, Polyetheretherketone Gasket, IO-Link, Model

Name: Turck LRS510 Series Radar Level Sensor, Stainless Steel Housing, Polyetheretherketone Gasket, IO-Link, Model
Brand: Turck
SKU: 166422
Price: 2177.04 USD
Availability: InStock



Category Level Sensors Brand Turck Condition New

Specifications

Country of Origin	Germany
Resolution	1 mm
Brand	Turck
Model	LRS510
Cable Length	10m
Housing Material	Stainless Steel
Series	LRS510
Maximum Operating Temperature	65°C
Maximum Pressure	16bar
Minimum Operating Temperature	-25°C
Maximum Current	250mA
Device Type	Radar
Interface Type	IO-Link
Maximum dc Voltage	33V dc
Hazardous Area Certification	FCC, ETSI 305550-2, CFR
Standards/Approvals	CE, ETSI, UL, FCC
Gasket Material	Polyetheretherketone

Key Features

Constructed with a durable stainless steel housing for corrosion resistance.
Equipped with a polyetheretherketone gasket ensuring reliable sealing.
Features a 10-meter cable length for flexible installation solutions.
Operates efficiently within a temperature range of -25°C to 65°C.
Utilizes IO-Link interface for seamless industrial communication.
Supports a maximum DC voltage of 33 volts and maximum current of 250 mA.
Designed to withstand pressures up to 16 bar for demanding environments.
Provides high resolution measurement with 1 mm accuracy.

Product Description

Turck presents the LRS510 Series Radar Level Sensor, model LRS510-10-57-2UPN8-H1141, featuring a robust stainless steel housing paired with a polyetheretherketone gasket designed for industrial level measurement. This sensor delivers precise distance, level, volume, or percentage output measurements with a beam cone angle of ±5° and a measurement resolution of 1 mm.

The device includes a rotatable 180° housing allowing optimal alignment after mounting on a 3/4" NPT process connection, supporting ranges up to 10 meters with a minimal blind zone of 35 cm. Supporting IO-Link interface, it facilitates seamless integration with industrial control systems, operating reliably across temperatures from -25°C to 65°C and sustaining pressures up to 16 bar.

Powered by a maximum DC voltage of 33 V and operational current up to 250 mA, this radar sensor meets CE, ETSI, UL, and FCC certifications, including hazardous area certifications (FCC, ETSI 305550-2, CFR), ensuring compliance and safe performance in challenging industrial environments.

Ideal for industrial automation, process control, water treatment, and manufacturing sectors, the Turck LRS510 radar level sensor reliably measures levels in liquids and solids, offering precise control to optimize processes and maintain safety standards.

Durable stainless steel housing with polyetheretherketone gasket ensures long service life. Rotatable housing for flexible installation on 3/4" NPT connections. 10-meter range with 35 cm blind zone and 1 mm resolution for accurate measurement.

IO-Link interface simplifies system integration and data communication. Certified to CE, ETSI, UL, and FCC standards including hazardous area approvals. Max operating pressure of 16 bar suitable for demanding industrial applications.

Wide operating temperature range from -25°C to 65°C for versatile deployment. Compact design reduces footprint while maintaining measurement accuracy. Manufactured in Germany ensuring high-quality industrial standards. Explore the Turck LRS510 Series in the Level Sensors category on EnvMart for reliable industrial automation solutions.
