LEM Current Transformer HAT Series 800A 15V 15mm Bore HAT 800-S

LEM HAT 800-S Current Transformer from the HAT Series is designed using Hall effect technology to accurately measure DC, AC, and pulse currents up to 800A. This open loop current transducer provides galvanic isolation ensuring safe electrical measurement and monitoring.

The device features a 15mm bore diameter suitable for busbar and plug-in mounting, with compact 90mm width and 10mm depth dimensions to fit industrial control panels and automation systems efficiently.

Its housing is manufactured from UL94-V0 rated self-extinguishing insulating material, enhancing safety and durability under demanding industrial conditions. Rated for operating temperatures from -40°C to 105°C, the transformer maintains stable performance across a wide temperature range.

Conforming to JEDEC JESD46-B standards and approved with CE marking, it is suitable for numerous industrial applications including process control, power monitoring, and automation. The 15V supply voltage ensures reliable operation while supporting integration with existing electrical systems.

Employs Hall effect measuring principle for accurate current sensing. Features galvanic isolation between primary and secondary circuits for safety. Constructed with UL94-V0 self-extinguishing insulating housing material.

Operates reliably in temperatures ranging from -40°C to 105°C. Designed for busbar and plug-in mount applications. Compliance with JEDEC JESD46-B standards ensures quality performance. Compact dimensions with 90mm width and 10mm depth facilitate versatile installation.

Supplied voltage of 15V supports efficient operation. Made in China with CE approval for international standards.

This current transformer is ideal for industrial, laboratory, automation, HVAC, manufacturing, and commercial electrical measurement and control tasks. Explore similar Current Transformer products and other precision electrical components on EnvMart.
