Honeywell Technologies FSG Series Button Load Cell, Compression and Tension Force Measurement, 0 N Min, 0.51 kg FSG005WNPB
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 9.91mm |
| Model | FSG005WNPB |
| Depth | 9.04mm |
| Sensor Type | Button |
| Width | 7.98mm |
| Mount Type | Surface |
| Housing Material | Plastic |
| Series | FSG |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Terminal type | Wire |
| Maximum dc Voltage | 10V dc |
| Force Measured | Compression, Tension |
| Maximum Force/Load Measurement | 0.51kg |
| Minimum Force/Load Measurement | 0N |
Key Features
- The button load cell features a compact design with a plastic housing.
- Operates reliably over a wide temperature range from -40°C to 85°C.
- Utilizes a piezo resistive micro-machined silicon sensing element.
- Suitable for surface mounting with wire terminal connections.
- Low deflection and low repeatability errors ensure accurate measurement.
- Low off-centre loading error improves system accuracy.
- Low power consumption makes it ideal for battery-operated applications.
- Maximum DC voltage rating of 10 V DC for safe operation.
Product Description
Honeywell FSG005WNPB Button Load Cell is a compact, commercial-grade force sensor designed for accurate compression and tension force measurement with a minimum of 0 N and a maximum force measurement capacity of 0.51 kg. It features a plastic housing with a surface mount design and wire terminal type connections. The sensor operates over a broad temperature range from -40°C to 85°C, making it suitable for various industrial, laboratory, and automation applications.
This load cell employs a specialized piezo resistive micro-machined silicon sensing element to provide extremely low deflection and low error rates in repeatability and linearity. Its low off-centre loading errors enhance system accuracy by minimizing mechanical misalignment effects. The device consumes low power, enabling its use in portable and battery-powered systems.
The maximum DC voltage rating is 10 V DC, making it compatible with low voltage measurement systems. Its precise dimensions of 7.98 mm width, 9.91 mm length, and 9.04 mm depth allow easy integration into compact sensor arrays and measurement setups.
The Honeywell FSG series button load cell is ideal for use in industrial automation, material testing, laboratory instrumentation, and force measurement applications requiring high accuracy and reliability.
The button Load Cell features a compact design with a plastic housing. Operates reliably over a wide temperature range from -40°C to 85°C. Utilizes a piezo resistive micro-machined silicon sensing element. Suitable for surface mounting with wire terminal connections.
Low deflection and low repeatability errors ensure accurate measurement. Low off-centre loading error improves system accuracy. Low power consumption makes it ideal for battery-operated applications. Maximum DC voltage rating of 10 V DC for safe operation.
Explore the full range of Honeywell sensors and force measurement solutions on EnvMart for precise industrial, laboratory, and automation applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Honeywell FSG005WNPB load cell has a maximum force measurement capacity of 0.51 kg.
This load cell operates reliably over a temperature range from -40°C to 85°C.
It features wire terminal type connections suitable for surface mounting.
The dimensions of this load cell are 9.91 mm in length, 7.98 mm in width, and 9.04 mm in depth.
It is designed to measure both compression and tension forces.
The maximum DC voltage rating for this load cell is 10 V DC.
It features low deflection and low repeatability errors, along with low off-centre loading errors that improve system accuracy.
The housing of the Honeywell FSG005WNPB load cell is made from plastic.
Yes, it has low power consumption, making it ideal for battery-operated applications.
This model is a button type load cell.
It is suitable for industrial automation, material testing, laboratory instrumentation, and force measurement applications.
The country of origin for this load cell is China.
