RS PRO 2 Output 200 VA Chassis Mount Transformer, 18 V AC, 230 V AC Primary, CE, RoHS, IECBSEN 615586, ASNZS 61558.1, 503-944

Free Delivery in India | Lowest Global Shipping Charges

RS PRO 2 Output 200 VA Chassis Mount Transformer, 18 V AC, 230 V AC Primary, CE, RoHS, IECBSEN 615586, ASNZS 61558.1, 503-944

Name: RS PRO 2 Output 200 VA Chassis Mount Transformer, 18 V AC, 230 V AC Primary, CE, RoHS, IECBSEN 615586, ASNZS 61558.1, 503-944
Brand: RS PRO
SKU: 164148
Price: 131.67 USD
Availability: InStock



Category Chassis Mount Transformer Brand RS PRO Condition New

Specifications

Country of Origin	Poland
Brand	RS PRO
Length	100mm
Model	503-944
Depth	65.82mm
Gross Weight	2.8kg
Width	92mm
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-30°C
Number of outputs	2
Primary Voltage	230 V ac
Secondary Voltage	18 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
Walsall Transformers 200VA 2 Output Chassis Mounting Transformer, 18V acBrand	Walsall Transformers

Key Features

Dual secondary outputs provide flexibility with independent windings.
Primary voltage rated at 230 V AC for standard industrial supply.
Compact chassis mount design with dimensions 100 x 92 x 65.82 mm.
Wide operating temperature range from -30°C to 70°C ensures reliability.
Meets CE, RoHS, IECBSEN 615586, and multiple ASNZS standards for safety.
Can connect secondary windings in series or parallel for variable voltage/current.
Suitable for electrical, industrial, and laboratory power transformation needs.
Manufactured with high-quality materials in Poland.

Product Description

RS PRO 503-944 is a high-quality 2 output chassis mount transformer with a power rating of 200 VA and a secondary voltage of 18 V AC. It operates on a 230 V AC primary supply, providing robust and safe electrical transformation for various industrial applications.

This Chassis Mount Transformer features a compact frame with dimensions of 100 mm length, 92 mm width, and 65.82 mm depth, making it easy to integrate into electrical enclosures and panels. It is constructed to withstand operating temperatures from -30°C up to 70°C, ensuring consistent performance in diverse environments.

The two independent secondary windings allow flexible electrical configurations, as they may be connected in series or parallel to achieve different voltage or current outputs according to application needs. This makes the transformer suitable for various commercial and industrial equipment requiring dual-voltage outputs.

Compliance with international standards including CE, RoHS, IECBSEN 615586, ASNZS 61558.1, and others guarantees the transformer meets stringent safety and environmental regulations. Its weight of 2.8 kg supports secure chassis mounting without risk of vibration or movement.

This product is ideal for use in industrial power supplies, electrical distribution panels, laboratory equipment, HVAC systems, and other commercial electrical setups requiring reliable voltage transformation.

Dual independent secondary windings configurable for series or parallel connection. 230 V AC primary voltage suitable for standard supply networks. Wide operating temperature range for harsh or varied environments. Compact chassis mount design for ease of installation.

Compliant with multiple international electrical safety and quality standards. Mass of 2.8 kg provides stability and durability. Manufactured in Poland under strict quality controls. Provides 200 VA of transformer power for medium-demand applications.

RoHS and CE certified assuring environmental compliance and safety. Explore more from RS PRO and find specialized electrical components like transformers, power supplies, and accessories at EnvMart for professional industrial and commercial needs.
