Eaton xPole Miniature Circuit Breaker, 3-Pole, 10A, Type C, 400V AC, 48V DC, 10kA Breaking Capacity 236422 PXL-C10/3

Eaton 236422 PXL-C10/3 Miniature Circuit Breaker is a high-performance 3-pole device designed for use in industrial, commercial, and residential electrical installations. It is rated for 10 amps current with Type C tripping characteristics, making it suitable for circuits with moderate inrush currents such as lighting and small motor loads.

This miniature circuit breaker operates reliably at 400V AC and 48V DC voltages and features a breaking capacity of 10 kiloamperes, ensuring efficient interruption of short-circuit faults to protect wiring and connected equipment.

The breaker mounts easily onto a standard DIN rail using a quick-fit mechanism with three locking positions, compatible with IEC/EN 60715 rails. Its ergonomic toggle switch enables simple manual resetting after a fault condition, while the electromagnetic trip mechanism provides instantaneous protection.

Designed for safety, it offers finger-proof and back-of-hand-proof protection according to IP20 standards, minimizing accident risk and complying with international IEC/EN 60898 standards. This model from Eaton's xPole PXL series features double terminals with lift and jaw connections top and bottom, allowing flexible bus bar arrangements and installation convenience.

The compact dimensions (52.5mm height, 80mm width, 60mm depth) facilitate installation in tight panels and switchboards, making it an ideal choice for building electrical distribution systems, motor controls, automation panels, and other industrial electrical setups.

Designed with 3 poles and a current rating of 10A for versatile electrical applications. Features Type C tripping characteristics suitable for general purpose usage. Operates at rated voltages of 400V AC and 48V DC with a breaking capacity of 10kA.

Equipped with a toggle switch reset actuator for easy manual operation. Mounts on DIN rails with quick-fit action and offers finger-proof and back-of-hand-proof safety compliance. Constructed with an IP20 rating, ensuring protection from touch and solid foreign objects.

Compact dimensions: height 52.5mm, width 80mm, depth 60mm for efficient panel space usage. Conforms to IEC and EN 60898 standards ensuring global electrical safety and performance compliance. Instantaneous break time electromagnetic tripping mechanism for fast fault response.

This Eaton Miniature Circuit Breaker is suitable for industrial, construction, commercial, and residential electrical protection applications, providing safe and reliable operation in low-voltage distribution systems. Choose Eaton’s PXL-C10/3 for durable and compliant circuit breaking solutions.
