TE Connectivity Pluggable Terminal Block, 4-Contact, 3.5 mm Pitch, 1 Row, Vertical Orientation, 150V AC, 8A 2350398-4

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Pluggable Terminal Block, 4-Contact, 3.5 mm Pitch, 1 Row, Vertical Orientation, 150V AC, 8A 2350398-4

Name: TE Connectivity Pluggable Terminal Block, 4-Contact, 3.5 mm Pitch, 1 Row, Vertical Orientation, 150V AC, 8A 2350398-4
Brand: TE Connectivity
SKU: 161545



Category Pluggable Terminal Blocks Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	150V ac
Brand	TE Connectivity
Colour	Green
Orientation	Vertical
Current	8A
Length	14.7mm
Depth	14.3mm
Width	7.7mm
Housing Material	Phosphor Bronze
Number of Rows	1
Pitch	3.5mm
Number of Contacts	4
Connector Gender	Male
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Spring

Key Features

Utilizes phosphor bronze housing material for durability.
Spring wire connection method enables secure and tool-less installation.
Supports wire size range from 24 AWG (0.05 mm²) to 16 AWG (1.31 mm²).
Compact dimensions of 14.7 mm length, 7.7 mm width, and 14.3 mm depth.
Green color coding allows easy identification.
Male connector gender designed for mating with compatible female connectors.

Product Description

TE Connectivity 2350398-4 pluggable terminal block is a high-quality electronic component engineered for efficient and reliable wire-to-board connections in industrial and control system applications. Featuring a 4-contact configuration on a single row, this terminal block operates at a current rating of 8 amperes and supports voltages up to 150V AC, making it suitable for a broad range of electronic and electrical assemblies.

Constructed with phosphor bronze housing, the terminal block ensures excellent mechanical strength and resistance to corrosion. The spring wire connection method allows for robust and tool-less insertion of ferruled and unferruled wires, improving installation times by up to 80% compared to traditional screw-clamp systems.

This component accommodates a wire size range from 0.05 mm² (24 AWG) up to 1.31 mm² (16 AWG) and is designed with a vertical orientation to optimize PCB space utilization. The green coloration supports easy visual identification during assembly and maintenance operations.

The terminal block measures 14.7 mm in length, 7.7 mm in width, and 14.3 mm in depth, making it compact for high-density applications. It is part of TE Connectivity's Buchanan portfolio of push-in clamp termination PCB connectors, widely utilized in industrial, manufacturing, automation, and telecommunications sectors.

Phosphor bronze housing material provides durability and corrosion resistance. Spring wire connection method enables secure, reliable, and tool-less wire insertion. Supports wire sizes from 24 AWG (0.05 mm²) to 16 AWG (1.31 mm²).

Compact dimensions fit high-density PCB layouts. Rated for 8A current and 150V AC voltage applications. Vertical orientation for efficient PCB space utilization.

This pluggable terminal block is ideal for use in control systems, power distribution boards, and various electronic devices requiring secure and easy-to-install wire connections. Its robust construction and standardized pitch support long-term reliability in industrial and commercial environments.
