Siemens SIWAREX WL Series Single Point Load Cell Compression Measurement 20 kg 7MH5102-2GD00

Free Delivery in India | Lowest Global Shipping Charges

Siemens SIWAREX WL Series Single Point Load Cell Compression Measurement 20 kg 7MH5102-2GD00

Name: Siemens SIWAREX WL Series Single Point Load Cell Compression Measurement 20 kg 7MH5102-2GD00
Brand: Siemens
SKU: 157796



Category Load Cell Brand Siemens Condition New

Specifications

Country of Origin	China
Brand	Siemens
Length	40mm
Model	7MH5102-2GD00
Depth	25mm
IP Rating	IP65
Sensor Type	Single Point
Width	25mm
Housing Material	Aluminium
Series	SIWAREX WL
Maximum Operating Temperature	65°C
Minimum Operating Temperature	-35°C
Terminal type	Screw
Maximum dc Voltage	12V dc
Standards/Approvals	OIML R60
Force Measured	Compression
Maximum Force/Load Measurement	20kg

Key Features

Accurate load sensing designed for compression force measurement.
Robust aluminium housing ensures durability and corrosion resistance.
IP65 rating provides protection against dust and water ingress.
Suitable for industrial environments with operating temperatures from -35°C to 65°C.
Single point sensor type allows straightforward installation and integration.
Equipped with screw terminals for reliable electrical connections.
Compliant with OIML R60 standards ensuring high measurement accuracy.
Ideal for automated weighing systems, packaging machinery, and industrial load monitoring.

Product Description

Siemens 7MH5102-2GD00 SIWAREX WL Series Single Point Load Cell is a precision sensor designed for reliable compression force measurement up to 20 kg. This load cell features a robust aluminium housing that balances durability with lightweight construction, making it suitable for demanding industrial applications.

The sensor is IP65 rated, ensuring effective protection against dust and water ingress, which makes it ideal for installation in harsh environments. Operating temperature ranges from -35°C to 65°C, allowing use across diverse industrial conditions.

With dimensions of 40 mm in length, 25 mm in width, and 25 mm in depth, this compact device integrates easily into automated weighing systems, packaging machinery, and machine monitoring setups. Equipped with screw terminals and designed as a single point load cell, it permits straightforward electrical connections and flexible installation.

Certified to meet OIML R60 standards, the SIWAREX WL Series load cell guarantees high accuracy and precision for industrial load measurement tasks. It operates at a maximum DC voltage of 12V, ensuring electrical safety and stability in operation.

Accurate load measurement within 20 kg compression range. Durable aluminium construction for resistance to corrosive environments. IP65 protection rating suitable for industrial use. Wide temperature operation from -35°C to 65°C.

Compact single point sensor for easy integration. Screw terminal type for secure electrical connections. Compliance with OIML R60 standards. Compact physical dimensions ensure versatile application. Suitable for automation, weighing, packaging, and machine monitoring.

Designed for 12V DC operation.

This Siemens single point Load Cell is a reliable choice for industrial, manufacturing, laboratory, and automation applications requiring precise force measurement and durability. Explore more Siemens sensing and automation solutions on EnvMart for high-quality industrial instrumentation needs.
