Microchip CAN Transceiver 8 Mbps, 8-Pin SOIC MCP2542FD-E/SN
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Microchip |
| Height | 1.5mm |
| Length | 4.9mm |
| Model | MCP2542FD-E/SN |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP2542FD |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Sub Type | CAN Transceiver |
| Minimum Operating Temperature | -40°C |
| Interface Type | ISO 11898-2, ISO 11898-5, CAN |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 4.5V |
| Supply Current | 70mA |
| Maximum Data Rate | 8Mbps |
| Number of Transceivers | 1 |
| Maximum Propagation Delay | 120 ns |
| Loop Delay Symmetry | ±10% (2 Mbps) |
Key Features
- Designed for high-speed CAN FD applications up to 8 Mbps data rate.
- Improved maximum propagation delay of 120 ns for extended bus length support.
- Operates over a supply voltage range of 4.5 to 5.5 V for reliable CAN bus interfacing.
- Low quiescent current with standby mode current as low as 4 µA.
- Complies with automotive standard AEC-Q100 ensuring robustness and quality.
- Supports CAN 2.0 and Flexible Data Rate CAN FD physical layer requirements.
- Wake-up on CAN activity with 3.6 µs filter time for low power management.
- ESD protection to provide high reliability in automotive and industrial environments.
Product Description
Microchip MCP2542FD-E/SN is a high-performance CAN transceiver designed for CAN FD automotive and industrial communication networks, supporting communication speeds up to 8 Mbps. It features improved propagation delay and symmetry to optimize long bus length performance and signal integrity.
This device supports both CAN 2.0 and CAN FD standards and operates efficiently with a supply voltage between 4.5 V and 5.5 V. It integrates a very low standby current mode of approximately 4 µA, enabling power-saving during inactive states.
The MCP2542FD-E/SN also provides wake-up functionality triggered by CAN bus activity with a filter time of 3.6 microseconds, making it suitable for low power applications and automotive bus systems.
Robust electrostatic discharge (ESD) protection and compliance with the AEC-Q100 automotive standard ensure durability and reliability in harsh environments. The CAN bus pins disconnect automatically in the event of device power loss, preventing bus loading by unpowered nodes or brown-out conditions.
High-speed CAN FD communication at up to 8 Mbps data rate. Improved bus length support due to low maximum propagation delay of 120 ns. Power down standby mode consuming only 4 µA of current. Wake-up on CAN bus activity with 3.6 µs filtering for noise immunity.
Automotive qualified to AEC-Q100 standard for quality assurance. Compact 8-pin SOIC surface mount package designed for space-saving PCB layouts. Supports ISO 11898-2 and ISO 11898-5 interface standards.
This CAN transceiver is ideally suited for industrial, automotive, and manufacturing applications requiring robust and reliable CAN FD physical layer connectivity. It is a suitable component for high-speed data buses, vehicle networks, and embedded system communication.
Explore related semiconductor and CAN Interface ICs categories on EnvMart for complementary products and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum data rate of 8 Mbps, making it suitable for high-speed CAN FD applications.
The MCP2542FD-E/SN operates over a supply voltage range of 4.5 V to 5.5 V, ensuring reliable performance in various applications.
This unit has dimensions of 4.9 mm in length, 3.9 mm in width, and 1.5 mm in height, designed for compact PCB layouts.
The maximum propagation delay is 120 ns, which helps optimize performance for extended bus lengths.
It complies with the AEC-Q100 automotive standard, ensuring robustness and quality for automotive applications.
The standby current is as low as 4 µA, allowing for efficient power management during inactive states.
This model supports ISO 11898-2 and ISO 11898-5 interface standards, suitable for CAN communication.
The operating temperature range is from -40°C to 125°C, making it suitable for various environmental conditions.
The MCP2542FD-E/SN includes one transceiver, designed for efficient CAN communication.
It features a wake-up on CAN bus activity with a filter time of 3.6 µs, enhancing low power management capabilities.
This model is designed for surface mount applications, facilitating easy integration into PCB designs.
The supply current for this model is 70 mA, which is typical for its operational requirements.
