STMicroelectronics High Side Solid State Relay Power Switch IC 10-Pin SOIC VN340SP-E

STMicroelectronics VN340SP-E High Side Solid State Relay Power Switch IC in a 10-pin SOIC package is engineered for efficient high side switching in electronic control systems. It integrates logic interface, drivers, diagnostics, and protection features, making it an intelligent power switch suitable for power management tasks in industrial electronics, automotive, and automation sectors.

The switch topology is high side, with a solid state relay switch type, ensuring fast, reliable switching with minimal power dissipation. Its low switch on resistance of 0.2Ω reduces losses, enhancing overall system efficiency. The device supports a minimum supply voltage of 1V and can handle up to 36V supply voltage, accommodating various circuit designs.

It supports 4 switch outputs and an operating current rating of 700mA, allowing multiple load controls. Mounting is surface mount to facilitate compact assembly on printed circuit boards. The operating temperature range from -55°C to 150°C ensures durability in harsh environments. Physical dimensions of 9.5mm length, 9.6mm width, and 3.65mm height are suitable for space-constrained applications.

The VN340SP-E complies with IEC 61131-2 standard for industrial control equipment, ensuring reliable and safe operation. This power switch IC is ideal for industrial automation, power management in machinery, automotive electronic controls, and other demanding applications requiring robust high side power switching with integrated protection and diagnostics.

The IC features a low on-resistance of 0.2 ohms for efficient power switching. It supports up to 4 outputs for multiplexed power control. Designed for surface mount application, it ensures compact PCB layout. Operates effectively between 1V minimum and 36V maximum supply voltages.

Handles continuous operating current of up to 700mA for robust performance. Wide operating temperature range from -55°C to 150°C supports industrial conditions. Compact dimensions of 9.5mm length, 9.6mm width, and 3.65mm height suit dense layouts.

Complies with IEC 61131-2 standards ensuring quality and safety in applications. Series VN340SP-E provides intelligent high side power switching with integrated diagnostics and protection. Discover the STMicroelectronics VN340SP-E and explore similar Power Switch ICs on EnvMart for your electronic design and industrial control projects.
