Artesyn Medical Grade Isolated DC-DC Converter 24V DC Input 840mA Output 20W Through Hole AEE20W-M

Artesyn AEE20W-M is a high-performance isolated DC-DC converter designed specifically for medical instrumentation and other demanding industrial applications. This converter provides a single output of 24 volts DC at 840 mA, delivering a maximum output power of 20 watts. It supports a wide input voltage range of 18 to 36 volts DC with a standard input of 24V DC, making it highly adaptable to various DC power sources.

The unit features 4200 Vac reinforced insulation, which meets stringent medical safety standards including 2x MOPP (Means of Patient Protection) for patient connected equipment. This specialized insulation provides supplementary or reinforced safety isolation as needed in medical and industrial equipment.

Designed as a through-hole mount device, the AEE20W-M measures 50.8 mm in length, 25.4 mm in width, and 12 mm in depth, with tinned copper pins for reliable soldering and mechanical stability. Its robust construction supports an operating temperature range from -40°C to +80°C, ensuring dependable operation under harsh environmental conditions.

The converter is certified according to ANSI AAMI ES60601-1 (medical standard), EMI EN55011, EMS EN60601-1-2, EN55022, EN IEC 60601-1, and FCC Level A, making it a trusted choice for compliance-critical industrial and medical applications. It delivers low ripple and noise (150 mV typical), which is critical for sensitive downstream electronic circuits.

Other features include isolation voltage of 4.2 kV DC and a MTBF (Mean Time Between Failures) rating of one million hours, reflecting the unit’s high reliability and long service life. The tinned copper pins ensure excellent electrical connectivity and resistance to corrosion. This compact, medical-grade converter is ideal for industries such as medical devices, laboratory instruments, manufacturing automation, and power management systems.

This product is manufactured in China and is supplied new. The Artesyn AEE20W-M DC-DC Converter combines advanced safety certification, high efficiency, and robust build quality for demanding industrial and medical power conversion needs.

Provides medical safety certification with 4200 Vac reinforced insulation. Wide 2:1 input voltage range from 18V to 36V DC for voltage flexibility. High efficiency of 89% ensures minimal energy loss during operation. Designed for demanding instrumentation requiring supplementary or reinforced insulation.

Compact through-hole package measures 50.8mm length by 25.4mm width and 12mm depth. Operational temperature range from -40°C to +80°C for reliable performance in harsh environments. Low ripple and noise of 150mV supports sensitive electronics.

Isolation voltage up to 4.2kV DC ensures strong electrical separation. Tinned copper pins enhance durability and connectivity reliability. Mean Time Between Failures (MTBF) rated at 1,000,000 hours indicating high reliability.
