Artesyn 10 W 12V DC 830 mA Through Hole Isolated DC/DC Converter ERM00B18
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters Artesyn ERM DC/DC Converter, 12V dc/ 830 mA, 36V d |
| Brand | Artesyn |
| Efficiency | 86% |
| Length | 50.8mm |
| Model | ERM00B18 |
| Depth | 11mm |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | ERM |
| Maximum Operating Temperature | 85°C |
| Package Type | Encapsulated |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 9V |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 830mA |
| Isolation Voltage | 3kV dc |
| Input Ratio | 4:1 |
| Input Ratio4 | 1 |
Key Features
- Provides isolated DC to DC conversion for industrial and railway applications.
- Encapsulated package with through-hole mount type for easy PCB integration.
- High efficiency of 86% supports reliable energy conversion.
- Supports maximum operating temperature up to 85°C and minimum down to -40°C.
- Reinforced insulation rated at 3 kV DC enhances safety in demanding environments.
- Compact standard footprint of 50.8 mm length x 25.4 mm width x 11 mm depth.
- Advanced protections include overload and short-circuit safeguards.
- Highly suitable for railway and transportation system power supplies.
Product Description
Artesyn ERM00B18 is a 10 watt isolated DC/DC converter module designed to provide stable 12 V DC output with 830 mA current. It operates efficiently within an input voltage range of 9 V to 36 V DC, making it suitable for use in industrial, railway, and transportation power systems requiring reliable voltage conversion.
This module features a robust encapsulated package with through-hole mount type, providing mechanical stability and ease of installation on printed circuit boards. Its compact dimensions of 50.8 mm length, 25.4 mm width, and 11 mm depth conform to industry-standard sizes.
The ERM00B18 ensures high efficiency at 86%, which reduces power loss and heat generation during operation. It supports a wide operating temperature range from -40°C up to 85°C, allowing deployment in harsh environments.
Designed with reinforced insulation rated at 3 kV DC, this converter guarantees safety and withstands high-voltage transients. It further incorporates advanced circuit topologies that provide protections against overloads and short circuits, ensuring longevity and reliable performance.
Typical applications include railway power systems, transportation equipment, and other industrial settings where compact, efficient, and durable DC/DC converters are essential. Provides isolated DC to DC conversion for industrial and railway uses.
Encapsulated metal case with through-hole mounting. High 86% efficiency for energy savings. Wide input voltage acceptance from 9 V to 36 V DC. Operating temperature range from -40°C to 85°C. Reinforced 3 kV DC insulation for safety.
Compact standard size footprint. Includes overload and short-circuit protection. Input voltage ratio of 4:1 to handle variations. Explore a wide range of power conversion solutions in the EnvMart DC/DC Converter category for reliable electronic system designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Artesyn ERM00B18 provides a stable output voltage of 12V DC with a maximum output current of 830 mA.
This DC/DC converter has an efficiency rating of 86%, which helps reduce power loss during operation.
It operates within an input voltage range of 9V to 36V DC, accommodating various power supply conditions.
The dimensions of the Artesyn ERM00B18 are 50.8 mm in length, 25.4 mm in width, and 11 mm in depth.
This model features a through-hole mount type, which allows for easy installation on printed circuit boards.
The maximum operating temperature for the Artesyn ERM00B18 is 85°C, making it suitable for various environments.
It includes reinforced insulation rated at 3 kV DC and advanced protections against overloads and short circuits.
The minimum operating temperature for this converter is -40°C, allowing it to function in extreme conditions.
This DC/DC converter is suitable for industrial, railway, and transportation power systems that require reliable voltage conversion.
The isolation voltage of the Artesyn ERM00B18 is rated at 3 kV DC, enhancing its safety in demanding environments.
The input ratio of this converter is 4:1, allowing it to handle variations in input voltage effectively.
The country of origin for this DC/DC converter is China.
