Artesyn DC/DC Converter 24V DC Output, 410 mA, 40-160V DC Input, 10 W, Through Hole Mount ERM00H110

Artesyn ERM00H110 DC/DC Converter is a high performance 10 watt isolated power module designed primarily for railway and transportation industrial applications. It features a single 24V DC output capable of 410 mA current, derived from a wide input voltage range of 40 to 160V DC, supporting diverse power supply environments.

Encapsulated fully in a rugged metal housing, this converter measures 50.8mm in length, 25.4mm in width, and 11mm in depth, making it ideal for compact PCB mounting with through-hole technology integration. The reinforced insulation withstands voltages up to 3kV DC, ensuring safe isolation and reliable operation in electrically noisy environments.

The ERM00H110 operates efficiently up to 85%, providing stable output power while maintaining low thermal dissipation, supported by an ambient temperature range of -40 °C to 85 °C with appropriate derating. These features make it well-suited for challenging operating conditions commonly encountered in transportation systems and industrial machines.

This converter also integrates advanced safety functionality including overload protection, short circuit protection, under voltage shutdown, remote on/off control, and voltage adjustment capabilities, enhancing system reliability and user control during operation.

Typical applications include use within industrial automation, railway systems, embedded computing, and any scenario requiring durable, reliable DC power conversion from a high voltage DC source to a regulated 24V output. Its industry standard footprint and encapsulated design simplify its implementation in critical power supply networks.

Designed for high performance in railway and transportation applications. Fully encapsulated metal case measuring 50.8 x 25.4 x 11 mm. Operating temperature range from -40 °C to 85 °C with suitable derating. High isolation voltage rated at 3kV DC with reinforced insulation.

Features advanced circuitry offering up to 85% efficiency. Includes protections for overload, short circuit, and under voltage shutdown. Industry standard 2 x 1 inch footprint for easy PCB integration. Offers a single output voltage of 24 V DC at 410 mA output current.

Input voltage range supports a wide 4:1 ratio from 40V to 160V DC. Suitable for industrial, railway, and transportation power conversion needs. Explore advanced DC/DC Converters and power supply components at EnvMart for industrial and transportation applications.
