Artesyn DC/DC Converter 24V DC Output 840mA, 12V DC Input, 20W Power, Through Hole Mount AEE20W-M
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters Artesyn AEE20W-M DC/DC Converter, 24V dc/ 840 mA |
| Brand | Artesyn |
| Efficiency | 89% |
| Length | 50.8mm |
| Model | AEE20W-M |
| Depth | 12mm |
| Gross Weight | 30g |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | AEE20W-M |
| Maximum Operating Temperature | 80°C |
| Package Type | 2 x 1 in |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 1 |
| Ripple and Noise | 150mV |
| Maximum Output Power | 20W |
| Maximum Input Voltage | 12V dc |
| Standards/Approvals | ANSI AAMI ES60601-1, Class A, EMI EN55011, EMS EN60601-1-2, EN 55022, EN IEC 60601-1, FCC, Level A |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 840mA |
| Isolation Voltage | 4.2kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Operating temperature range | - 40 °C to +85 °C |
| Wide 2 | 1 input voltage range |
Key Features
- Compact footprint measuring 50.8mm length, 25.4mm width, and 12mm depth.
- High efficiency of 89% to optimize power consumption.
- Reliable isolation voltage rated at 4.2kV DC for safe operation.
- Wide operating temperature range from -40°C to 80°C suitable for industrial environments.
- Meets multiple industry standards including ANSI AAMI ES60601-1 and EMI EN55011 Class A.
- Low ripple and noise output at 150mV for sensitive electronics.
- High MTBF rating of 1,000,000 hours indicating long reliability.
- Lightweight design weighing only 30 grams facilitating easy integration.
Product Description
Artesyn AEE20W-M is a high-quality DC/DC converter designed for industrial and medical electronic applications requiring isolated 24V DC power output. This model delivers a continuous output current of 840mA with a maximum output power of 20W, powered by a stable 12V DC input voltage with a wide 2:1 input ratio enhancing voltage input flexibility.
The converter features a compact through-hole mounting package measuring 50.8mm in length, 25.4mm in width, and 12mm in depth, making it suitable for space-constrained printed circuit boards. Its isolation voltage is rated at 4.2kV DC to assure electrical safety between input and output circuits.
Equipped with high efficiency rated at 89%, this converter helps minimize heat generation and improves energy efficiency in power supply systems. It operates reliably in a temperature range from -40°C up to 80°C, supporting deployment in harsh industrial environments.
The device complies with various international standards such as ANSI AAMI ES60601-1 for medical safety and EMI/EMS standards including EN55011 Class A and FCC Level A, making it suitable for precise and sensitive equipment.
Additional features include low output ripple and noise at only 150mV and an impressively high mean time between failures (MTBF) of 1,000,000 hours, ensuring durable and stable operation over time. With its lightweight design of only 30 grams, the AEE20W-M facilitates easy assembly into embedded systems.
Compact through-hole mount design for PCB integration. Wide 2:1 input voltage range offers greater operational flexibility. High isolation voltage supports safe medical and industrial applications. Robust industrial temperature range supports extreme conditions.
Certified to numerous EMI and safety standards for reliability. Low ripple and noise enhances sensitive electronic equipment performance. High efficiency reduces power loss and heat dissipation. Long operational life with 1,000,000 hours MTBF rating.
This Artesyn DC/DC Converter is ideal for medical devices, industrial control systems, and power supply designs that demand small, efficient, and isolated voltage conversion. Explore more DC and voltage converters within the Electronics & Electricals category at EnvMart for comprehensive power management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output voltage of 24V DC and a continuous output current of 840mA.
The maximum output power of this converter is 20W.
It has an efficiency rating of 89%, optimizing power consumption.
The isolation voltage is rated at 4.2kV DC, ensuring safe operation between input and output circuits.
This unit measures 50.8mm in length, 25.4mm in width, and 12mm in depth.
It operates reliably within a temperature range from -40°C to 80°C.
It meets multiple industry standards including ANSI AAMI ES60601-1 and EMI EN55011 Class A.
This converter weighs only 30 grams, facilitating easy integration into systems.
The ripple and noise output is low at 150mV, suitable for sensitive electronics.
It features a through-hole mounting design, ideal for PCB integration.
The MTBF rating is 1,000,000 hours, indicating long reliability.
It requires a stable 12V DC input voltage with a wide 2:1 input ratio for enhanced flexibility.
