Artesyn 20W High Performance ERM DC/DC Converter 5V dc Output, 4 A Output Current, 40-160V dc Input, Through Hole ERM04A110
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters Artesyn ERM DC/DC Converter, 5V dc/ 4 A, 160V dc I |
| Brand | Artesyn |
| Efficiency | 84% |
| Length | 50.8mm |
| Model | ERM04A110 |
| Depth | 11mm |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | ERM |
| Maximum Operating Temperature | 85°C |
| Package Type | Encapsulated |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 20W |
| Maximum Input Voltage | 160V dc |
| Minimum Input Voltage | 40V |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 4A |
| Isolation Voltage | 3kV dc |
| Input Ratio | 4:1 |
| Input Ratio4 | 1 |
Key Features
- Designed for high performance isolated DC/DC power conversion applications.
- Suitable for railway and transportation system use with reinforced insulation rated at 3000 Vac rms.
- Fully encapsulated metal case with standard 2 x 1 inch footprint and 11mm height for compact installation.
- Operating temperature range from -40°C to 85°C ensuring reliable performance in harsh environments.
- Advanced circuit topology achieving 84% efficiency and providing remote On/Off, undervoltage shutdown and protection features.
- Single output configuration with through hole mounting for straightforward PCB integration.
- Encapsulated package type ensuring robust mechanical durability and EMI immunity.
- Widely used in industrial, railway, and transportation power supply systems.
Product Description
The Artesyn ERM04A110 is a 20 watt high performance DC/DC converter module designed specifically for use in industrial and railway applications requiring isolated power supply. It features a 5V DC output voltage with a maximum output current of 4 A, accepting a wide input voltage range of 40 V to 160 V DC. The module is fully encapsulated within a metal case with a compact footprint of 50.8 mm length by 25.4 mm width and a low profile height of 11 mm, facilitating easy integration into compact electronic systems.
This DC/DC converter supports through hole mounting, which ensures robust mechanical connection and excellent thermal performance. The device offers reinforced insulation rated for 3 kV DC isolation, enhancing safety and meeting stringent railway and transportation system standards. Its electrical design includes advanced circuit topology that delivers up to 84% efficiency, helping reduce power losses and thermal stress.
The ERM04A110 operates reliably across a broad temperature range from -40°C minimum to 85°C maximum, providing high ambient temperature tolerance with appropriate derating. Additional features include voltage adjustment capability, remote On/Off control, undervoltage shutdown, overload protection, and short circuit protection to safeguard downstream circuitry and ensure system stability.
This product is ideal for power supply design in demanding industrial environments, railway signaling, automation controls, transportation systems, and electronic equipment requiring isolated DC power conversion. The encapsulated package enhances durability, electromagnetic interference immunity and mechanical protection.
High efficiency 20W isolated power converter. Wide input voltage range from 40V to 160V DC. 5V DC output voltage at 4A continuous current. Robust through hole mounting and compact size. Reinforced insulation to 3kV DC isolation standard.
Operating temperature -40°C to +85°C. Protection features include undervoltage, overload and short circuit. Designed for industrial and railway power applications. Encapsulated metal package for EMI immunity and ruggedness.
Choose the Artesyn ERM04A110 DC/DC Converter for reliable isolated power conversion in your next industrial or transportation project. Explore more DC/DC Converter modules and power supply solutions from Artesyn and other trusted brands at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 20 watts.
It accepts a wide input voltage range from 40V to 160V DC.
The Artesyn ERM04A110 has an efficiency rating of 84%.
This model has a length of 50.8 mm, a width of 25.4 mm, and a height of 11 mm.
It provides a 5V DC output voltage with a maximum output current of 4A.
This unit supports through hole mounting for straightforward PCB integration.
The operating temperature range is from -40°C to 85°C.
It features reinforced insulation rated for 3kV DC isolation.
It includes undervoltage shutdown, overload protection, and short circuit protection.
This model is widely used in industrial, railway, and transportation power supply systems.
It comes in a fully encapsulated metal package type, enhancing durability and EMI immunity.
This model is part of the ERM series of DC/DC converters.
