Cosel PCB Mount DC-DC Converter 5V DC Output 2A 5V DC Input 4.5V Input 10W 7-Pin SIP-8 MGS100505
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGS DC/DC Converter, 5V dc/ 2 A, 5V dc Input |
| Brand | Cosel |
| Efficiency | 87% |
| Length | 22mm |
| Model | MGS100505 |
| Depth | 12mm |
| Gross Weight | 7g |
| Width | 9.5mm |
| Mount Type | PCB |
| Series | MGS |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 300mV Pk-Pk |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 5V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 2A |
| Output Voltage Adjustment Range | 4.90 to 5.21 V |
| Isolation Voltage | 1kV dc |
| Output Current 2 | 0.2A |
Key Features
- Compact 7-pin SIP-8 package for easy PCB mounting.
- Operates within an input voltage range of 4.5V to 5V DC.
- Maximum operating temperature up to 85°C with -40°C minimum.
- Offers output voltage adjustment range between 4.90V to 5.21V.
- Features high efficiency of 87 percent for energy saving.
- Provides 1kV DC isolation voltage ensuring safety in isolated power supply applications.
- Integrated overcurrent protection for robust performance.
- Ripple and noise level is low at 300mV peak-to-peak for signal integrity.
Product Description
Cosel MGS100505 is a PCB mount DC-DC Converter designed to provide a stable 5V DC output at 2A with a maximum power rating of 10W. It supports an input voltage range from 4.5V to 5V DC, enabling compatibility with varying power sources in industrial and electronic component applications. Its compact design features a 7-pin SIP-8 package, facilitating easy integration into standard PCB footprints.
This converter operates efficiently with an 87% conversion rate and maintains operational reliability across a wide temperature range from -40°C to 85°C. The device also features an output voltage adjustment capability between 4.90V and 5.21V for precise voltage control.
The MGS100505 offers 1kV DC isolation voltage, enhancing safety and reducing noise in sensitive power environments. Its low ripple and noise specifications of 300mV peak-to-peak make it suitable for noise-sensitive industrial applications. Integrated overcurrent protection ensures device and system safety under load stress.
This power supply unit complies with multiple international safety standards including cUL, UL62368-1, EN 62368-1, RoHS, C-UL, UL60950-1, CSA, CE, and UKCA certifications. Manufactured in Japan, it delivers quality and reliability for various electronics and industrial power applications requiring isolated DC/DC conversion.
Compact 7-Pin SIP-8 package for PCB mounting ease. Wide operating temperature range from -40°C to 85°C. High efficiency of 87% for power conservation. Integrated overcurrent protection for safe operation. 1kV DC isolation voltage for electrical safety.
Low ripple and noise of 300mV peak-to-peak for clean output. Output voltage adjustable from 4.90V to 5.21V. Compliant with major international electrical safety standards. Suitable for industrial and electronic component power supply needs.
Manufactured in Japan with high-quality standards. Explore the full range of Cosel DC/DC Converters available at EnvMart for reliable and efficient power supply solutions tailored to industrial and electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 10W.
It supports an input voltage range from 4.5V to 5V DC.
It has an efficiency rating of 87%.
The dimensions are 22mm in length, 12mm in depth, and 9.5mm in width.
The output voltage can be adjusted between 4.90V and 5.21V.
It offers a 1kV DC isolation voltage.
The operating temperature range is from -40°C to 85°C.
The ripple and noise level is low at 300mV peak-to-peak.
It is designed for PCB mounting with a 7-pin SIP-8 package.
It includes integrated overcurrent protection for safe operation.
It is manufactured in Japan.
This model has one output.
