Lapp Circular Connector, 12 Contacts, Cable Mount, M23 Size, Plug Male, IP68 Rated, EPIC CIRCON Series 44420037 + 73002720
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 100V |
| Brand | Lapp |
| Orientation | Straight |
| Current | 7A |
| Model | 44420037 + 73002720 |
| IP Rating | IP68 |
| Mount Type | Cable |
| Housing Material | Zinc |
| Contact Material | Copper |
| Series | EPIC CIRCON |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -25°C |
| Pole Format | 12 |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shell Size | M23 |
| Mating Type | Keyed |
| Connector Size | M23 |
| Plug/Socket | Plug |
| Coding | N |
Key Features
- Features a keyed mating system to prevent misalignment during installation.
- Constructed with nickel-plated zinc housing for excellent mechanical protection.
- Provides strong resistance against vibration, corrosion, and electromagnetic interference.
- Rated for operation between -25°C and 125°C, suitable for harsh environments.
- Includes an integrated shielding ring for 360-degree EMI protection and a sealing FPM gasket for moisture and dust resistance.
- Designed according to DIN Specification EN61984 for industrial circular connectors.
- Capable of carrying up to 7A current at 100V voltage rating.
- Uses solder termination and gold-plated copper alloy pins for optimal conductivity and durability.
Product Description
Lapp 44420037 + 73002720 circular connector is a high-quality industrial cable-mounted plug featuring 12 gold-plated copper alloy contacts. It is part of the EPIC CIRCON M23 series, designed for demanding industrial environments with key features such as IP68 ingress protection, vibration resistance, and EMI shielding.
The connector features a keyed mating system that ensures precise alignment and ease of assembly. Its nickel-plated zinc housing provides robust mechanical protection and corrosion resistance, while the integrated 360-degree EMI shielding ring minimizes signal interference, improving overall system reliability.
The FPM seal ring offers outstanding protection against moisture and dust, making the connector suitable for use in harsh settings ranging from -25°C to +125°C. With a current rating of 7A at 100V, this cable connector supports reliable electrical performance for various industrial applications.
Termination is achieved via soldering, and the contacts are made of gold-plated copper alloy to provide excellent conductivity and long-lasting durability. The CIRCON M23 series connectors are compliant with DIN Specification EN61984 and are ideal for systems such as printing presses, measurement instrumentation, and advanced robotics.
Features a keyed mating system to prevent misalignment during installation. Nickel-plated zinc housing offers excellent corrosion and mechanical resistance. Vibration resistant design suitable for installation near moving machinery.
Incorporates EMI shielding to reduce signal interference. Rated for IP68 protection against dust and moisture ingress. Wide operating temperature range from -25°C to +125°C. Gold-plated copper alloy contacts for optimal conductivity and durability.
Solder termination type ensures secure electrical connection. Compliant with DIN Specification EN61984 for industrial connectors.
This circular connector from Lapp is engineered for industrial, robotic, measurement, and printing press applications where durability and reliability under harsh conditions are critical. It ensures secure and stable cable connections and is backed by German engineering quality with the EPIC CIRCON series.
Explore EnvMart’s Electronics & Electricals category for more Industrial Circular Connectors and related components with trusted brand standards and specifications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 7A and a voltage of 100V.
It has an IP68 rating, providing protection against dust and moisture ingress.
The housing is made of nickel-plated zinc, and the contacts are gold-plated copper alloy.
It operates within a temperature range of -25°C to 125°C, making it suitable for harsh environments.
This circular connector features 12 contacts.
It uses solder termination for secure electrical connections.
Yes, it is engineered for industrial, robotic, measurement, and printing press applications.
It features a keyed mating system to prevent misalignment during installation.
The shell size of this model is M23.
It includes an integrated shielding ring for 360-degree EMI protection, reducing signal interference.
The country of origin for this product is Germany.
This connector has a male contact gender.
