Cosel High Efficiency DC/DC Converter 12V DC 16.7A, 24V DC Input, 200.4W Output Power, PCB Mount, CHS3002412-B
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel CHS DC/DC Converter, 12V dc/ 16 |
| Brand | Cosel |
| Efficiency | 92% |
| Length | 58.9mm |
| Model | CHS3002412-B |
| Depth | 12.7mm |
| Gross Weight | 50g |
| Width | 12.7mm |
| Mount Type | PCB |
| Series | CHS |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 180mV Pk-Pk |
| Maximum Output Power | 200.4W |
| Maximum Input Voltage | 24V dc |
| Maximum Switching Frequency | 170kHz |
| Minimum Input Voltage | 18V |
| Number of Pins | 8 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 16.7A |
| Isolation Voltage | 1kV ac |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
Key Features
- Provides high efficiency up to 92 percent ensuring energy savings.
- Supports wide input voltage range from 18V to 24V DC for versatile use.
- Features built-in remote On/Off control for operational convenience.
- Compact DIP package with dimensions 58.9mm x 12.7mm x 12.7mm for efficient space utilization.
- Offers high reliability with no aluminium or tantalum electrolytic capacitors inside.
- Rated for robust 1kV AC isolation voltage enhancing safety standards.
- Designed for operation between -40°C and 85°C temperature range.
- Includes built-in protections for overcurrent and overvoltage safeguarding the circuit.
Product Description
Cosel CHS3002412-B is a high performance DC/DC converter designed for industrial and telecommunications applications requiring reliable power conversion. It provides a stable 12V DC output at a maximum current of 16.7A and power rating of 200.4W from an input voltage range of 18V to 24V DC. The unit supports PCB mounting with a compact DIP package measuring 58.9mm in length and 12.7mm in both width and depth, making it suitable for dense electronic assemblies.
This converter achieves an excellent efficiency of 92 percent, reducing energy loss and heat generation during operation. The design omits aluminium and tantalum electrolytic capacitors to enhance longevity and reliability. It features built-in remote On/Off capability, as well as overcurrent and overvoltage protections to safeguard downstream electronics and enhance operational safety.
The isolation voltage rating of 1kV AC provides protection against electrical faults, while the operating temperature range from -40°C to 85°C ensures stable performance in harsh environments. These characteristics, coupled with compliance to CE, cUL, CSA, UL standards, make the CHS3002412-B converter well suited for use in telecommunications equipment, industrial control systems, and other demanding electronic applications.
High efficiency up to 92 percent for energy saving. Wide input voltage range from 18V to 24V DC. Compact DIP package for PCB mounting (58.9 x 12.7 x 12.7 mm). Reliable operation between -40°C and 85°C ambient temperature.
Remote On/Off function for convenient control. Built-in overcurrent and overvoltage protection. 1kV AC isolation voltage for enhanced safety. No aluminium or tantalum electrolytic capacitors, improving durability. Suitable for telecommunications and industrial electronics.
Certified to CE, cUL CSA 60950-1, UL 60950-1 standards.
Cosel's CHS series DC/DC converters are trusted industrial components engineered for reliable power supply performance. Explore more from Cosel and related DC/DC Converters on EnvMart for your electronic design and power management requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 200.4W.
It supports a wide input voltage range from 18V to 24V DC.
This converter achieves an efficiency of up to 92 percent.
The dimensions of the converter are 58.9mm in length, 12.7mm in width, and 12.7mm in depth.
It is designed to operate within a temperature range of -40°C to 85°C.
This model is designed for PCB mounting.
Yes, it includes built-in protections for overcurrent and overvoltage.
The isolation voltage rating is 1kV AC, providing enhanced safety.
This converter has one output.
The ripple and noise is specified at 180mV peak-to-peak.
The gross weight of this model is 50g.
It is suitable for industrial and telecommunications applications requiring reliable power conversion.
