MEAN WELL ELG-150 Series IP67 1 Output LED Driver, 42V, 150W, 900mA Potentiometer Dimmable

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL ELG-150 Series IP67 1 Output LED Driver, 42V, 150W, 900mA Potentiometer Dimmable

Name: MEAN WELL ELG-150 Series IP67 1 Output LED Driver, 42V, 150W, 900mA Potentiometer Dimmable
Brand: MEAN WELL
SKU: 138379



Category LED Driver Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	ELG-150
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Current/Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	150W
Input Voltage	180, 305, 254, 431V ac
Output Voltage	42V
Power Dissipation	150W
Standards/Approvals	CB, CE:CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
Dimming Operation	Potentiometer
Primary Type	AC-DC, DC-DC
Driver Current	900mA
Standards/ApprovalsCB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
CB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750

Key Features

The driver operates with a wide input voltage range of 180 to 431 V AC.
It offers IP67 rating ensuring protection against dust and water ingress.
The constant current and constant voltage operating modes provide versatility.
Robust encapsulated metal housing for durability and heat dissipation.
Fan-less design increases efficiency with up to 91% efficiency rating.
Supports both potentiometer and PWM signal dimming methods.
Includes built-in active PFC to reduce power losses.
Designed for LED street lighting, architectural lighting, bay lighting, and floodlighting applications.

Product Description

MEAN WELL ELG-150-42B is an IP67 rated LED driver from the ELG-150 series designed for powering high-quality LED applications. It delivers 42V output voltage and provides a maximum output power of 150W with a constant current of 900mA. This dimmable LED driver features a potentiometer dimming operation and supports both constant current and constant voltage modes, making it highly versatile for various LED lighting systems.

The driver accepts a wide input voltage range between 180 V AC and 431 V AC, accommodating fluctuations in power supply. Constructed in a sturdy full metal encapsulated housing, it offers excellent heat dissipation and durability suitable for industrial and outdoor use. The fan-less design ensures silent operation and an efficiency rating of up to 91%, reducing power wastage and operational costs.

With an IP67 ingress protection rating, the MEAN WELL ELG-150-42B is highly resistant to dust and water, making it suitable for harsh and wet environmental conditions. This feature makes it ideal for industrial outdoor lighting, including LED street lamps, architectural lighting, bay lighting, and floodlighting installations.

The LED driver includes built-in active power factor correction (PFC), contributing to improved energy efficiency and reduced harmonic distortion on the power grid. Dimming control can be adjusted via a potentiometer or PWM signal, providing user flexibility for brightness settings.

The unit is certified with internationally recognized standards such as CB, CE, CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, UL8750, ensuring compliance with safety and reliability protocols.

The driver operates at a constant current of 900mA and delivers 150W power. Input voltage ranges from 180 to 431 V AC with screw terminal mounting. Encapsulated design enhances protection and longevity. Suitable for demanding industrial, commercial, and architectural LED lighting applications.

Efficient fan-less operation with high ingress protection for outdoor use.

MEAN WELL LED drivers such as the ELG-150-42B series provide reliable power solutions tailored for LED lighting and are widely used in construction, manufacturing, commercial infrastructure, and municipal lighting projects. EnvMart offers an extensive range of LED Drivers to facilitate innovative lighting designs and installations.
