MEAN WELL IP67 1 Output Dimmable LED Driver 42V 100W 600mA Constant Current/Voltage Driver

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 1 Output Dimmable LED Driver 42V 100W 600mA Constant Current/Voltage Driver

Name: MEAN WELL IP67 1 Output Dimmable LED Driver 42V 100W 600mA Constant Current/Voltage Driver
Brand: MEAN WELL
SKU: 138368



Category LED Drivers Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	ELG-100
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Current/Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	100W
Input Voltage	180, 305, 254, 431V ac
Output Voltage	42V
Power Dissipation	100W
Standards/Approvals	CB, CE:CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
Primary Type	AC-DC, DC-DC
Driver Current	600mA
Standards/ApprovalsCB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
CB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750

Key Features

Fan-less design ensures high efficiency and silent operation.
Robust full metal housing for durability and IP67 rating for water and dust resistance.
Supports both potentiometer and PWM signal dimming.
Wide input voltage range of 180 to 431V AC for versatile use.
Class 2 power unit with built-in active power factor correction (PFC).
Designed for LED street, architectural, bay, and flood lighting applications.
Single output configuration with constant current and constant voltage operation modes.
Screw mount type with wire terminal connection for easy installation.

Product Description

MEAN WELL ELG-100-42B IP67 1 Output Dimmable LED Driver is a high-performance LED driver delivering 42V output and 100W power with 600mA constant current. Its fan-less design provides excellent efficiency and silent operation, making it ideal for various industrial and commercial LED lighting systems.

The robust full metal housing ensures durability and environmental protection with its IP67 rating, suitable for outdoor and harsh conditions. The driver features a wide operating input voltage range from 180 to 431V AC, accommodating varying power supply conditions.

Dimming is flexible with both potentiometer and PWM signal options, allowing precise control of light intensity. It is designed as a Class 2 power unit with built-in active power factor correction for energy-efficient operation.

This LED driver is widely used in industrial, architectural, street, bay, and flood lighting applications, providing stable and reliable power for LED modules. Its screw mount and wire terminal make installation straightforward and secure.

Fan-less design ensures high efficiency and silent operation. Robust full metal housing for durability and IP67 protection. Supports potentiometer and PWM dimming methods. Wide input voltage range of 180 to 431V AC. Class 2 power unit with active PFC for improved energy efficiency.

Suitable for LED street, architectural, bay, and flood lighting. Constant current and voltage operation modes. Screw mount with wire terminal type connection.

MEAN WELL LED drivers are trusted components for reliable LED lighting in industry, commercial, and outdoor environments. Browse more LED Drivers and power supplies on EnvMart for comprehensive lighting solutions.
