JST PUD Series Right Angle Through Hole PCB Header, 14 Contacts, 2 mm Pitch, 2 Row, Shrouded S14B-PUDSS-1(LF)(SN)

Free Delivery in India | Lowest Global Shipping Charges

JST PUD Series Right Angle Through Hole PCB Header, 14 Contacts, 2 mm Pitch, 2 Row, Shrouded S14B-PUDSS-1(LF)(SN)



Category PCB Header Brand JST Condition New

Specifications

Country of Origin	Japan
Voltage	250V
Brand	JST
Orientation	Right Angle
Current	3A
Model	S14B-PUDSS-1(LF)(SN)
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	PUD
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
Number of Rows	2
Pitch	2mm
Contact Plating	Tin
Number of Contacts	14
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Features a compact, high-density double row layout for stable contact performance.
Designed for through hole mounting with right angle positioning on PCB boards.
Constructed with copper alloy contacts and tin plating for reliable conductivity.
Low insertion force with audible locking mechanism for secure mating with sockets.
Operates reliably within a temperature range of -25°C to 85°C.
Rated for 250 V voltage and 3 A current capacity.
Suitable for high vibration environments ensuring connection stability.
Shrouded housing provides protection and polarization to prevent incorrect mating.

Product Description

JST S14B-PUDSS-1(LF)(SN) Right Angle Through Hole PCB Header connector features 14 male contacts arranged in two rows with a 2 mm pitch, ideal for reliable wire-to-board connections. This shrouded header ensures optimum polarisation and protection during mating and is designed for use in high vibration environments where contact stability is critical.

Manufactured with copper alloy contacts plated with tin, this PCB header supports a voltage rating of 250 V and a current rating of 3 A, making it suitable for moderate power PCB interconnections in electronics, industrial, and manufacturing applications.

The product utilizes a through hole mounting style with a right angle orientation, facilitating compact PCB layouts while maintaining secure solder termination. It incorporates a locking mechanism delivering an audible click when mated with its socket counterpart for confident assembly verification.

Its operational temperature range spans from -25°C to 85°C, allowing usage in diverse environmental conditions common in electronic control systems, instrumentation, and embedded devices.

This product is an essential component within PCB Headers offering wire-to-board connectivity and is compatible with a range of JST's PUD series connectors designed for efficient, stable board interconnections.

Compact high-density double row design ensures stable connections. Right angle orientation optimizes PCB space utilization. Copper alloy contacts with tin plating provide conductivity and corrosion resistance. Locking mechanism offers secure mating with audible confirmation.

Rated for 3 A current and 250 V voltage for moderate power applications. Operating temperature from -25°C to 85°C for diverse applications. Shrouded for protection and polarization.

Ideal for electronics manufacturing, industrial automation, consumer electronics, and other applications requiring reliable PCB connector solutions. Explore EnvMart's extensive range of electronic components and JST connectors for your project needs.
