TDK-Lambda DC/DC Converter 12V DC Output 2.5 A, 24V DC Input, 9V Min Input, 30W, Through Hole CCG30-24-12S

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda DC/DC Converter 12V DC Output 2.5 A, 24V DC Input, 9V Min Input, 30W, Through Hole CCG30-24-12S

Name: TDK-Lambda DC/DC Converter 12V DC Output 2.5 A, 24V DC Input, 9V Min Input, 30W, Through Hole CCG30-24-12S
Brand: TDK-Lambda
SKU: 135959
Price: 69.81 USD
Availability: InStock



Category DC/DC Converter Brand TDK-Lambda Condition New

Specifications

Country of Origin	India
Voltage	Converters / DC-DC Converters TDK-Lambda CCG 30 DC/DC Converter, 12V dc/ 2
Brand	TDK-Lambda
Efficiency	89%
Length	25.4mm
Model	CCG30-24-12S
Depth	9.9mm
Gross Weight	20g
Width	9.9mm
Mount Type	Through Hole
Series	CCG 30
Maximum Operating Temperature	85°C
Package Type	DIP
Minimum Operating Temperature	-40°C
MTBF	3191064h
Number of outputs	1
Ripple and Noise	95mV Pk-Pk
Maximum Output Power	30W
Maximum Input Voltage	24V dc
Standards/Approvals	L 60950-1, RoHS, EN 60950-1, CSA 60950-1, CE mark
Minimum Input Voltage	9V
Number of Pins	6
Output Voltage 1	12V dc
Output Current 1	2.5A
Output Voltage Adjustment Range	13.5/16.5 V
Isolation Voltage	1.5kV dc

Key Features

This converter features a maximum operating temperature of 85°C and minimum of -40°C to ensure reliable operation under harsh conditions.
It utilizes a through-hole mount type with a DIP package measuring 25.4mm length, 9.9mm width and depth for easy PCB integration.
The device offers high efficiency up to 89% and includes six-sided shielding to minimize noise and improve thermal management.
It supports output voltage adjustment within the range of 13.5 to 16.5 V and has an isolation voltage of 1.5kV DC for safety.
Ideal for industrial, broadcast, communication, factory automation and process control applications requiring isolated DC power conversion.

Product Description

TDK-Lambda CCG30-24-12S is a high-performance DC/DC Converter designed for robust industrial and electronic applications. It converts DC input voltages from 9V up to 24V into a regulated 12V DC output at 2.5 A, delivering a total output power of 30W. Encased in a metal housing with six-sided shielding, this converter ensures low noise operation and withstands shock and vibration.

The converter operates within an ambient temperature range of -40°C to +85°C, making it suitable for harsh environments. Its through-hole DIP package with dimensions of 25.4mm x 9.9mm x 9.9mm allows easy PCB mounting and assembly.

With an efficiency rating of 89%, the CCG30-24-12S converter ensures reduced power loss and easier system thermal management. The output voltage can be adjusted between 13.5 V and 16.5 V, providing flexibility for varying application requirements. Featuring an isolation voltage of 1.5kV DC, it ensures safety in electrical isolation-sensitive environments.

This converter series is widely used in test and measurement devices, broadcast equipment, communication hardware, general industrial devices, factory automation systems, and process control units.

This series offers wide input voltage range and high efficiency performance. The metal enclosure with six-sided shielding reduces radiated noise for sensitive electronics. It facilitates easier thermal management in compact designs.

The device supports remote on/off operation for system integration. The DIP through-hole footprint matches industry-standard 1 inch x 1 inch size. Its robust design and reliable performance make the TDK-Lambda CCG30-24-12S an ideal choice for professional electronic and industrial DC power conversion needs.

Explore this and other TDK-Lambda DC-DC converters to enhance your power supply solutions at EnvMart.
