Sifam Tinsley DE Analogue Panel Ammeter 100 A AC, 0.5 % Moving Iron EQ44-I1622N1CAW0ST

Free Delivery in India | Lowest Global Shipping Charges

Sifam Tinsley DE Analogue Panel Ammeter 100 A AC, 0.5 % Moving Iron EQ44-I1622N1CAW0ST

Name: Sifam Tinsley DE Analogue Panel Ammeter 100 A AC, 0.5 % Moving Iron EQ44-I1622N1CAW0ST
Brand: Sifam Tinsley
SKU: 135646
Price: 19.64 USD
Availability: InStock



Category Analogue Panel Ammeter Brand Sifam Tinsley Condition New

Specifications

Country of Origin	India
Brand	Sifam Tinsley
Model	EQ44-I1622N1CAW0ST
Depth	54mm
Series	DE
Maximum Operating Temperature	55°C
Current Type	AC
Meter Accuracy	0.5 %
Minimum Operating Temperature	-10°C
Standards/Approvals	VDE 0110, IEC 1010, DIN IEC 61554, IEC51/DINEN60051, DIN 43701, DIN 40050, 2004/108/EC, DIN 43802, 93/68/EEC, DIN 46200/46282, IEC 529, UL 94 V-0, IS : 1248, VDE 0410, IS 9249, DIN 43807, IEC 60051, VDE / VDI 3540, DIN 43718, 2006/95/EC
Minimum Measurement	100 mA, 6 V
Maximum Measurement	1000V, 100 A
Moving Element	Moving Iron
Maximum Ampere Value	100 A

Key Features

Measures AC current up to 100 A with 0.5% accuracy.
Features a moving iron type measuring element for reliable readings.
Designed with a 54mm depth suitable for panel installation.
Operates in temperatures between -10°C and 55°C.
Complies with international standards such as VDE, IEC, DIN, and UL.
Constructed with glass filled polycarbonate housing for durability.
Includes a knife edge pointer for precise scale reading.
Scale interchangeability allows flexible measurement options.

Product Description

Sifam Tinsley EQ44-I1622N1CAW0ST Analogue Panel Ammeter is a DE series instrument designed for measuring AC currents up to 100 A with high precision and reliability. This model utilizes a moving iron measuring element, providing an accuracy rating of 0.5% for dependable readings in industrial and automation environments.

The meter is housed in a robust glass filled polycarbonate case with a depth of 54mm, making it ideal for panel mounting in control systems. It features a knife edge pointer and near linear scale for clear and accurate scale reading, with scale interchangeability to accommodate different measurement requirements.

Operating temperature ranges from -10°C to 55°C, the device meets numerous international standards including VDE 0110, IEC 1010, DIN IEC 61554, IEC51/DIN EN 60051, and UL 94 V-0 among others, ensuring compliance and safety.

This Analogue Panel Ammeter is designed for use in industrial automation, process control, electrical panels, and other commercial applications requiring precise current measurement. The panel meter supports frequencies from 15 to 400 Hz and voltages from 15 to 100 Hz.

High accuracy 0.5% rating ensures precise AC current measurement. Durable polycarbonate housing for industrial-grade protection. Knife edge pointer provides clear indication. Wide temperature operating range from -10°C to 55°C.

Comprehensive standards compliance including VDE, IEC, DIN, UL. Scale interchangeability allows flexibility in measurements. Moving iron mechanism for reliable, stable measurements. Compact 54mm depth suits diverse panel installations.

Ideal for industrial automation and process control systems.

Manufactured in India, this panel ammeter offers a trusted solution for precise AC current monitoring needs. Explore similar products and categories at EnvMart for comprehensive automation and control gear options.
