Pepperl + Fuchs Block Inductive Proximity Sensor M20 x 1.5 2-Wire 60V 15 mm Detection NBB15-U1-Z2

Pepperl + Fuchs NBB15-U1-Z2 Block Inductive Proximity Sensor is engineered for industrial and automation applications requiring reliable object detection and position feedback. Featuring a compact block-style polyamide housing with an M20 x 1.5 thread size, this sensor supports flush mounting for flush embedding in metal surfaces while maintaining excellent durability and environmental protection.

The sensor operates at a maximum DC supply voltage of 60V and switching current of 200mA. Its unshielded sensing face allows for a maximum detection distance of 15 mm and supports high switching frequencies up to 400 Hz, providing fast and accurate response times. This makes it ideal for conveyor monitoring, assembly line control, and machinery safety systems.

Designed to withstand harsh industrial environments, the NBB15-U1-Z2 is rated IP68 and IP69K, ensuring resistance against dust, water, and high-pressure washdowns. It operates reliably within a temperature range from -25°C to 85°C, suitable for diverse conditions in manufacturing, material handling, and process control industries.

This sensor includes integrated reverse polarity and short circuit protection to safeguard against electrical faults, enhancing operational security. The 2-wire output simplifies installation and reduces wiring complexity.

Certifications to CCC, CSA, EN 60497-5-2:2007, IEC 60947-5-2:2007, and UL highlight compliance with international safety and quality standards, making it a trusted choice worldwide.

This product originates from Vietnam and is part of the Varikont series known for exceptional robustness and reliability under demanding applications. Compact block style housing with M20 x 1.5 threading for flush mounting.

Polyamide material ensures durability and UV resistance. IP68 and IP69K ratings provide dust-tight and waterproof protection. High switching frequency of 400 Hz for rapid response. Robust temperature range of -25°C to +85°C ideal for industrial environments.

2-wire output facilitates straightforward electrical connections. Reverse polarity and short circuit protection for enhanced safety. Complies with CCC, CSA, EN and IEC international standards. Explore our full range of industrial sensors at EnvMart for superior automation and control solutions tailored to your application needs.
