Eaton xEffect Miniature Circuit Breaker 2-Pole 1A Type D 415V AC 10 kA Breaking Capacity 278768 FAZ-D1/2

The Eaton 278768 FAZ-D1/2 xEffect Miniature Circuit Breaker is a high-quality, reliable electrical protection device designed to safely interrupt electrical fault currents and protect circuits from damage. This 2-pole circuit breaker has a rated current of 1 ampere and conforms to Type D tripping characteristics, suitable for applications requiring delayed tripping to accommodate inrush currents.

Operating at a rated AC voltage of 415V, it can safely interrupt fault currents up to 10 kA, enhancing system safety in industrial, commercial, and residential electrical installations. The thermal magnetic trip mechanism provides six levels of protection by combining both thermal and magnetic tripping features, ensuring accurate and dependable operation.

The device mounts easily onto standard DIN rails, making installation and maintenance efficient. Its toggle switch design not only facilitates reset operations but also allows sealing in both on and off positions to prevent unauthorized switching. The compact dimensions, with a width of 85mm and a depth of 73mm, help optimize panel space usage.

Electrical connectivity is flexible with twin-purpose terminals that support different wiring types. Its IP20 rating offers protection against entry of solid objects larger than 12mm and finger access, suitable for indoor control panel environments.

Reliable 2-pole miniature circuit breaker for control panel applications. Precise 1A current rating with Type D tripping for delayed action. Robust 10 kA breaking capacity enhances circuit protection. DIN rail mount simplifies installation and integration.

Toggle switch actuator for easy reset and locking. Thermal magnetic tripping mechanism ensures safe operation. Twin-purpose terminal design for wiring flexibility. Compact size fits easily into electrical enclosures. IP20 rated for protection against solid foreign objects.

Ideal for supplementary protection in industrial and commercial electrical systems.

This Eaton xEffect miniature circuit breaker is suitable for use in electrical, industrial, commercial, and automation systems requiring dependable circuit protection. Its compact design, robust construction, and reliable tripping characteristics make it a trusted choice for enhanced electrical safety and operational continuity.
