3M 25 Way Right Angle 1.27 mm Pitch Cable D-Sub Connector Female 8325-6000

Free Delivery in India | Lowest Global Shipping Charges

3M 25 Way Right Angle 1.27 mm Pitch Cable D-Sub Connector Female 8325-6000



Category D-Sub Connector Brand 3M Condition New

Specifications

Country of Origin	India
Brand	3M
Orientation	Right Angle
Current	1A
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	8300
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Pitch	1.27mm
Standards/Approvals	RoHS, UL 94V-0
Contact Plating	Gold over Nickel
Number of Contacts	25
Contact Gender	Female
Connector Gender	Female
RS PRO 25 Way Straight 1.27 mm Pitch Cable D-Sub Connector FemaleRS Stock No.	642-4913Brand: RS PRO

Key Features

Compatible with tooling stock numbers 120-6962 and 192-7748 for efficient assembly.
Constructed with copper alloy contacts plated with gold over nickel for superior conductivity.
Housing material is durable polybutylene terephthalate suitable for industrial use.
Operates safely within temperature ranges from -55°C to 105°C.
Designed as a Class II D metal shell connector ensuring robust mechanical and electrical performance.
Right angle, cable-mounted female connector suitable for heavy-duty computing and industrial electronics.
Includes tin plating with dimples on shell for excellent grounding and EMC protection.
Ideal for use in industrial computers, medical equipment, and office computing applications.

Product Description

3M 8325-6000 25 Way Right Angle 1.27 mm Pitch Cable D-Sub Connector Female is a Class II metal shell connector developed to provide a reliable and durable connection in harsh environments. Manufactured using a copper alloy with gold over nickel plating for contacts and a polybutylene terephthalate housing, this connector combines mechanical strength with excellent electrical performance.

It supports current up to 1 ampere and is designed with a right angle cable mount and female contact gender, making it suitable for wiring harnesses and cable assemblies where space saving and secure connections are critical.

The connector operates effectively across a broad temperature range from -55°C to 105°C, making it suitable for industrial, medical, and commercial electronic applications. Its robust metal shell with tin plating and dimples ensures superior grounding, electromagnetic compatibility, and protection against interference.

3M's 8300 series connectors are well known for offering Class II performance and are compatible with selected tooling accessories (stock no. 120-6962 and 192-7748) to facilitate installation. They are also widely used with 3M colour-coded ribbon cables (stock no. 120-8485 and others), providing versatility in complex wiring configurations.

Compatible with tooling stock numbers 120-6962 and 192-7748 for efficient assembly. Constructed with copper alloy contacts plated with gold over nickel for superior conductivity. Housing material is durable polybutylene terephthalate suitable for industrial use.

Operates safely within temperature ranges from -55°C to 105°C. Designed as a Class II D metal shell connector ensuring robust mechanical and electrical performance. Right angle, cable-mounted female connector suitable for heavy-duty computing and industrial electronics.

Includes tin plating with dimples on shell for excellent grounding and EMC protection. Ideal for use in industrial computers, medical equipment, and office computing applications.

This 3M D-Sub Connector series is trusted in various sectors such as industrial computing, medical equipment, laboratory instrumentation, and commercial electronics due to its reliable mechanical integrity and signal performance.
